1

00:00:00,633 --> 00:00:02,466

iPhone trigger circuit

2

00:00:03,200 --> 00:00:08,866

In this lesson, we will learn how to measure the switch pin voltage and standby power supply

3

00:00:09,933 --> 00:00:12,933

Let's take the iPhone XS model as an example

4

00:00:13,800 --> 00:00:15,500

We first find the switch pin

5

00:00:16,366 --> 00:00:20,633

In the bitmap, find the iPhone XS power-on measurement point

6

00:00:24,566 --> 00:00:28,733

According to the mark, let's measure the switch pin in the real thing

7

00:00:29,433 --> 00:00:32,600

First, we buckle the boot cable to the mainboard

8

00:00:33,233 --> 00:00:37,066

Black pen grounding, red pen measuring switch pin

9

00:00:39,500 --> 00:00:45,133

At this time, we can see that the switch pin voltage is about 1.76 volts

10

00:00:45,633 --> 00:00:47,866

Now let's measure the standby power supply

11

00:00:48,033 --> 00:00:51,000

Let's start by opening the bitmap on the iPhone xs

12

00:00:51,666 --> 00:00:53,900

Select the Find button in the bitmap,

13

00:00:54,600 --> 00:00:56,133

select the search signal,

14

00:00:56,433 --> 00:00:59,933

enter PP1V8_ALWAYS, and click Search

15

00:01:00,366 --> 00:01:06,066

After searching, the yellow dot in the bitmap is the measurement point with standby power supply

16

00:01:07,066 --> 00:01:09,100

We connect the power supply cable

17

00:01:10,533 --> 00:01:13,866

The mainboard of xs needs to be layered to be measured

18

00:01:15,133 --> 00:01:17,500

We have already layered this mainboard

19

00:01:17,833 --> 00:01:21,600

We connect the black pen to the ground, and take the red pen to measure

20

00:01:21,933 --> 00:01:26,166

At this point, we can see that the voltage is around 1.8V

21

00:01:26,766 --> 00:01:28,933

So that's all for this lesson
