1

00:00:00,566 --> 00:00:03,133

We first prepare two or three bad batteries,

2

00:00:03,133 --> 00:00:05,800

and then prepare a pair of old test pens

3

00:00:08,566 --> 00:00:10,466

First remove the battery charging board

4

00:00:17,933 --> 00:00:19,700

Remove the plastic tab,

5

00:00:22,100 --> 00:00:23,900

and then flatten the battery board

6

00:00:30,400 --> 00:00:32,633

We add some tin on the weld position

7

00:00:32,633 --> 00:00:34,000

to burn off the battery board

8

00:01:01,733 --> 00:01:03,533

OK, the battery is removed

9

00:01:05,333 --> 00:01:07,000

Let's remove another piece

10

00:01:26,033 --> 00:01:29,766

The T-shaped head of the battery is soldered on with a soldering iron,

11

00:01:29,800 --> 00:01:31,966

we can't just rip it off from here

12

00:01:34,266 --> 00:01:37,100

If it is torn off, it cannot be soldered

13

00:01:38,233 --> 00:01:40,500

because it cannot be stained with tin

14

00:01:40,866 --> 00:01:43,033

So the T-shaped head has to stay here

15

00:01:44,866 --> 00:01:48,700

When cutting the lines, one is longer and the other is shorter,

16

00:01:49,766 --> 00:01:52,600

so that the two test pens will not touch each other

17

00:01:52,900 --> 00:01:54,800

and will not be short-circuited

18

00:02:06,133 --> 00:02:09,266

After cutting the wire, we put tin on the wires,

19

00:02:10,000 --> 00:02:11,933

which is convenient for us to solder

20

00:02:14,066 --> 00:02:17,400

The positive and negative poles of the battery must correspond,

21

00:02:18,400 --> 00:02:21,366

the positive pole is welded with the red wire,

22

00:02:21,533 --> 00:02:24,366

and the negative pole is welded with the black wire

23

00:02:24,966 --> 00:02:28,666

Put the two batteries together and flatten the position of the solder wire

24

00:02:32,733 --> 00:02:36,366

We clip the wire between the batteries and add a little tin

25

00:02:53,100 --> 00:02:56,133

After soldering, we add some more tin to the position

26

00:02:56,133 --> 00:02:58,000

of the two pads to make it stronger

27

00:03:11,400 --> 00:03:15,400

In this way, we have welded the positive and negative poles firmly

28

00:03:15,866 --> 00:03:18,166

Next we'll take tape and stick it up

29

00:03:24,900 --> 00:03:27,366

Okay, so we're done with the burning battery

30

00:03:27,566 --> 00:03:29,366

If the burning battery is dead,

31

00:03:29,366 --> 00:03:32,100

we can charge it with an adjustable power supply

32

00:03:32,466 --> 00:03:36,133

The power supply voltage is adjusted to 4.2V,

33

00:03:36,133 --> 00:03:38,400

the current can be 1A or the maximum,

34

00:03:38,500 --> 00:03:42,133

the positive pole of the power supply is clipped with a red test pen,

35

00:03:42,333 --> 00:03:46,366

and the negative pole is clipped with a black test pen, so that it can be charged

36

00:03:46,933 --> 00:03:49,666

When the adjustable power supply shows no current,

37

00:03:50,033 --> 00:03:51,933

it means the battery is fully charged
