iPhone audio circuit repairing

2

00:00:03,233 --> 00:00:09,866

This video mainly explains how to find the I2S bus from the iPhone 12 and 12 Pro models to the CPU

3

00:00:11,700 --> 00:00:16,600

After the bus has a problem, it will cause no handset and no transmission failure

4

00:00:17,000 --> 00:00:22,833

Search method step 1, find the baseband chip in the component map and confirm the position number

5

00:00:24,366 --> 00:00:28,566

Step 2, search for the position number in the circuit diagram

6

00:00:30,033 --> 00:00:34,533

Step 3, after finding the baseband, check the pins

7

00:00:36,400 --> 00:00:41,066

I2S is the audio bus from the CPU to the baseband when making a call

8

00:00:43,600 --> 00:00:49,033

Step 4, jump to the bitmap according to the pin, and view the connected components

9

00:00:49,600 --> 00:00:53,366

The diode value can be measured at the position of the yellow point in the bitmap

10

00:00:53,966 --> 00:01:01,200

When checking the maps, first open the component maps, circuit diagrams, and bitmaps of iPhone 12 and 12 Pro

11

00:01:01,866 --> 00:01:06,333

Find the baseband chip in the component map and confirm the position number

12

00:01:07,266 --> 00:01:10,400

Then search for the position number in the schematic diagram

13

00:01:11,233 --> 00:01:13,566

Because the baseband has many solder points,

14

00:01:14,366 --> 00:01:18,400

to prevent mistakes when searching, we click Advanced Search

15

00:01:19,000 --> 00:01:24,200

After clicking Advanced Search, there will be a list about the pages of the baseband chip

16

00:01:24,633 --> 00:01:26,300

Let's view them in turn

17

00:01:27,300 --> 00:01:34,166

In the list, the pin of the baseband chip marked with I2S represents the audio bus from the CPU to the baseband

18

00:01:34,766 --> 00:01:40,166

The I2S bus has a total of 4 lines, which are connected to the CPU by the baseband

19

00:01:41,133 --> 00:01:44,600

Pin AF30 of the baseband chip is the detection clock of the I2S bus

20

00:01:45,200 --> 00:01:47,266

Jump to the bitmap according to the name,

21

00:01:47,566 --> 00:01:51,633

the detection clock is connected to the CPU through the middle connection point

22

00:01:52,766 --> 00:01:56,433

Pin AF32 is the data output of the I2S bus

23

00:01:57,066 --> 00:01:59,066

Jump to the bitmap according to the name,

24

00:01:59,433 --> 00:02:03,600

the data output pin is connected to the CPU through the middle connection point

25

00:02:04,100 --> 00:02:08,333

Pin AG31 of the baseband chip is the data input of the I2S bus

26

00:02:08,633 --> 00:02:09,766

Jump to the bitmap,

27

00:02:10,066 --> 00:02:13,833

the data input pin is connected to the CPU through the middle connection point

28

00:02:15,533 --> 00:02:19,066

Pin AH30 is the serial clock of the I2S bus

29

00:02:19,633 --> 00:02:21,600

Jump to the bitmap according to the name,

30

00:02:21,933 --> 00:02:25,900

the serial clock is connected to the CPU through the middle connection point

31

00:02:26,733 --> 00:02:30,733

If there is no handset and no call failure after the iPhone is dropped,

32

00:02:31,500 --> 00:02:36,366

it is mostly because the I2S bus between the baseband and the CPU is disconnected

33

00:02:36,833 --> 00:02:39,833

We can measure the diode value of the I2S bus

34

00:02:41,266 --> 00:02:47,266

If the value is normal, we only need to reball the tin to fix the failure of no transmission and no handset

35

00:02:48,466 --> 00:02:50,233

That's all for this video
