iPhone common buses
2
00:00:03,333 --> 00:00:06,866
In this video, we mainly explain the buses in the iPhone mainboard
3
00:00:11,533 --> 00:00:12,666
Bus overview
4
00:00:12,866 --> 00:00:15,300
Bus refers to the line used to exchange data
5
00:00:15,300 --> 00:00:18,233
between components in electronic products
6
00:00:18,600 --> 00:00:22,866
This line provides data transfer and control logic for each component
7
00:00:23,366 --> 00:00:27,433
For example, Xiaoming takes a bullet train from Beijing to Shanghai
8
00:00:27,633 --> 00:00:29,733
Xiaoming can be understood as data,
9
00:00:30,066 --> 00:00:33,933
and the line that the bullet train takes can be understood as a bus
10
00:00:34,400 --> 00:00:38,300
The name of the train line is Beijing-Shanghai high-speed railway
11
00:00:38,566 --> 00:00:39,766
Then in the mainboard,
12
00:00:39,933 --> 00:00:43,566
the lines that transmit data from chips will also have names
13
00:00:45,000 --> 00:00:50,066
For example, the data bus from CPU to display is called MIPI bus,
14
00:00:50,200 --> 00:00:53,866
which is mainly used to transmit data between CPU and display
15
00:00:55,600 --> 00:00:58,466
There will be many kinds of buses in iPhones,
16
00:00:59,000 --> 00:01:03,366
and the data transmitted by these buses are different and have different names
17
00:01:03,700 --> 00:01:06,200
According to the bus block diagram of iPhone,
18
00:01:06,533 --> 00:01:10,400
we can see that there are many lines between the CPU and each chip,
19
00:01:11,466 --> 00:01:13,566
the lines are marked with names,
20
00:01:13,633 --> 00:01:17,200
and the data transmitted by different lines are also different
21
00:01:18,633 --> 00:01:21,766
Let's take a look at the meaning, function, identification
22
00:01:21,766 --> 00:01:23,766
and failure phenomenon of each bus
