1

00:00:01,233 --> 00:00:02,900

iPhone mobile phone commonly used bus

2

00:00:03,400 --> 00:00:07,033

In this video, we mainly explain the SPI bus

3

00:00:07,900 --> 00:00:11,700

The SPI bus is a full-duplex synchronous serial bus developed by Motorola.

5

00:00:15,333 --> 00:00:18,600

For communication between microcontrollers and external devices

6

00:00:19,600 --> 00:00:22,500

SPI works in master-slave mode

7

00:00:22,733 --> 00:00:24,666

Generally there is one master device and one or more slave devices

9

00:00:27,833 --> 00:00:30,633

The CPU is equivalent to the master device

10

00:00:31,066 --> 00:00:33,833

It is connected to audio, hard disk, touch screen and fingerprint through SPI bus

12

00:00:37,600 --> 00:00:40,033

These devices are slave devices

13

00:00:40,766 --> 00:00:43,300

The SPI bus consists of four wires

14

00:00:43,733 --> 00:00:45,200

In some circuits, three wires will work fine

16

00:00:47,566 --> 00:00:49,166

The main signals of this line are

18

00:00:51,566 --> 00:00:52,600

MOSI, master output slave input

20

00:00:55,766 --> 00:00:56,933

MISO, master input slave output

twenty two

00:00:59,366 --> 00:01:02,200

SCLK is the clock signal, generated by the master device

twenty four

00:01:04,800 --> 00:01:08,133

cs Chip selection is sent by the master device, which device is used to control the communication

26

00:01:11,200 --> 00:01:14,766

There are many devices used in the iPhone mobile phone

27

00:01:15,033 --> 00:01:17,566

For example, the main audio to the CPU, and the hard disk to the CPU also have an SPI bus

29

00:01:22,100 --> 00:01:26,733

The touch screen to the CPU is also through the SPI bus

30

00:01:27,100 --> 00:01:28,666

The fingerprint to the CPU is also transmitted through the SPI bus

32

00:01:31,766 --> 00:01:34,433

Is there anything listed in the frame diagram?

33

00:01:34,666 --> 00:01:36,066

e.g. compass, gyroscope, barometric pressure sensor

35

00:01:38,533 --> 00:01:39,533

These peripherals also transmit data through the SPI bus

37

00:01:42,966 --> 00:01:45,800

If there is a problem with the SPI bus, the corresponding function will not be available.

39

00:01:50,766 --> 00:01:53,400

Below we take the iPhone 8P Qualcomm motherboard as an example to check the SPI bus from the touch screen to the CPU

41

00:01:58,033 --> 00:01:59,133

We first find the display touch connection socket on the annotation diagram

43

00:02:02,966 --> 00:02:05,833

Then go to the drawing to search for the connection seat

44

00:02:06,566 --> 00:02:08,900

After finding the connecting seat, we can see that there are many English words on both sides of the connecting seat

46

00:02:11,766 --> 00:02:13,500

As long as the SPI is marked, it belongs to the SPI bus

48

00:02:15,000 --> 00:02:17,500

If TOUCH is marked, it means it is the SPI bus of the touch screen

50

00:02:20,500 --> 00:02:23,766

SPI TOUCH TO AP MISO refers to data output

53

00:02:26,133 --> 00:02:28,733

The SPI AP TO Touch CS signal is a signal for the CPU to select the touch screen when communicating with the touch screen

57

00:02:34,800 --> 00:02:39,200

MOSI stands for Data In

58

00:02:39,333 --> 00:02:42,200

SPI AP TO TOUCH SCLK is the SPI bus clock from the CPU to the touch screen

60

00:02:49,066 --> 00:02:52,333

iPhone 8 p touch screen has 4 SPI signals

61

00:02:52,633 --> 00:02:55,533

Then the CPU to the fingerprint is also the SPI bus

62

00:02:55,600 --> 00:02:58,733

But the bus uses three lines, the search method is the same as above

64

00:03:00,266 --> 00:03:03,166

After finding the connecting seat, we can see the English of the line identification

66

00:03:05,233 --> 00:03:09,100

The one that identifies SPI represents the SPI bus

67

00:03:09,333 --> 00:03:11,166

Among them, 15 feet, 17 feet, and 21 feet

70

00:03:13,733 --> 00:03:17,066

These English names all contain spi

71

00:03:17,233 --> 00:03:19,166

That means that these three lines belong to the SPI bus from the fingerprint to the CPU

73

00:03:22,700 --> 00:03:25,100

Among other pins, we can see that there is no SPI mark

75

00:03:28,300 --> 00:03:32,433

That means the SPI of the fingerprint only uses three lines

76

00:03:32,666 --> 00:03:34,966

That bus is connected to the CPU

77

00:03:35,266 --> 00:03:38,600

We can check the connection through the bitmap

78

00:03:41,066 --> 00:03:42,333

In the bitmap, each bus passes through one or two fuse resistors

81

00:03:47,266 --> 00:03:49,266

Then connect to the cpu

82

00:03:51,866 --> 00:03:54,566

The clock of the SPI bus passes through two fuse resistors to the cpu

84

00:03:57,366 --> 00:03:58,733

data input from the bus

85

00:04:00,600 --> 00:04:04,066

The data input is connected to the CPU through a safety inductor FL5840

88

00:04:08,066 --> 00:04:10,800

21 pin data output

89

00:04:13,233 --> 00:04:16,333

The signal is connected to the cpu after passing through the R5844 fuse resistor

92

00:04:20,800 --> 00:04:22,900

It can be clearly seen from the diagram we just checked

94

00:04:24,900 --> 00:04:28,000

The SPI bus of the fingerprint is connected to the CPU

95

00:04:28,300 --> 00:04:30,066

After the SPI bus is damaged, the corresponding functions will be unavailable

97

00:04:33,400 --> 00:04:36,000

If the SPI bus of the touch screen is damaged, it will cause no touch

99

00:04:38,200 --> 00:04:39,866

If the SPI bus of the fingerprint is damaged, the fingerprint function will be unavailable

101

00:04:42,700 --> 00:04:45,166

That's all for this video
