1

00:00:01,066 --> 00:00:02,900

iPhone mobile phone commonly used bus

2

00:00:03,166 --> 00:00:07,033

In this video, we mainly explain the RFFE bus

3

00:00:07,466 --> 00:00:09,066

The RFFE bus is an interface standard for mobile terminal RF front-end control introduced by the MIPI Alliance in 2010

8

00:00:20,100 --> 00:00:22,000

The RFFE bus consists of a power line and two control lines

11

00:00:28,033 --> 00:00:29,966

The bus line is simple and easy to deploy

12

00:00:30,733 --> 00:00:33,833

It enables near real-time control within timing range requirements

14

00:00:36,033 --> 00:00:38,700

In Apple's machines, it is generally used in the detection line between the baseband and the phone chip

18

00:00:45,300 --> 00:00:48,266

Through the iPhone bus architecture diagram, we can see

19

00:00:48,466 --> 00:00:52,866

The RFFE bus used in the middle of the baseband to radio frequency, power amplifier, antenna switch and filter

twenty one

00:00:56,600 --> 00:00:58,500

This bus is the baseband chip used to detect and control calls

twenty three

00:01:02,233 --> 00:01:05,600

After the RFFE bus of the baseband has a problem, the common faults are as follows:

25

00:01:07,533 --> 00:01:09,866

No service, signal diving

26

00:01:10,500 --> 00:01:13,133

In severe cases, the baseband does not work

27

00:01:13,633 --> 00:01:16,933

For example, after we plug in the phone card, it will show China Mobile

29

00:01:19,500 --> 00:01:21,666

Then came the mobile signal

30

00:01:22,033 --> 00:01:23,633

Wait for about 10 seconds, the machine shows no service again

32

00:01:26,266 --> 00:01:30,233

Wait another 10 seconds or so, it will appear China Mobile

33

00:01:30,366 --> 00:01:33,566

This fault phenomenon belongs to the signal diving

34

00:01:33,866 --> 00:01:35,500

Add it down, let's find the RFFE bus in the drawing

36

00:01:40,033 --> 00:01:43,233

Let's take the iPhone x Qualcomm model as an example

38

00:01:47,366 --> 00:01:51,033

In the annotation map, we first find the baseband position number

39

00:01:52,633 --> 00:01:54,766

Go to the drawing to search for the baseband position number

40

00:01:56,166 --> 00:01:57,500

After searching for the baseband, we base on the English name outside the block diagram

42

00:02:00,233 --> 00:02:02,633

As long as the English logo RFFE, it represents the bus

44

00:02:08,100 --> 00:02:10,666

In the current interface, we can see

45

00:02:10,866 --> 00:02:14,066

RFFE is marked in English outside the block diagram

46

00:02:14,733 --> 00:02:19,333

That means the line refers to the RFFE bus

47

00:02:19,633 --> 00:02:21,900

There are many sets of this model

48

00:02:23,366 --> 00:02:26,566

From RFFE1 to RFFE6, there are 6 groups of RFFE buses

51

00:02:32,333 --> 00:02:33,866

These 6 groups of buses detect different chips

53

00:02:36,266 --> 00:02:38,333

Let's go check it out

54

00:02:40,666 --> 00:02:44,400

After RFFE1 is sent from the baseband, it passes through the fuse resistor, and then connects to the radio frequency

56

00:02:47,733 --> 00:02:49,133

RFFE3 is sent out through the baseband and then connected to these amplifiers

58

00:02:54,433 --> 00:02:56,033

The chips that make calls are all detected and controlled by the baseband through the RFFE bus.

61

00:03:02,333 --> 00:03:04,933

We'll stop here in this lesson
