1

00:00:01,100 --> 00:00:04,100

iPhone mobile phone commonly used bus

2

00:00:04,100 --> 00:00:06,866

In this video, we mainly explain the PEIe bus

3

00:00:07,066 --> 00:00:08,300

PCIe bus is a high-speed serial computer expansion bus

5

00:00:11,933 --> 00:00:15,400

It was proposed by Intel in 2001 to replace the old PCI, PCI-X and AGP bus standards

8

00:00:21,766 --> 00:00:25,633

The PCIe bus is also used in our mobile phones

9

00:00:25,900 --> 00:00:28,833

There are many versions of the PCIe bus

10

00:00:29,100 --> 00:00:30,166

Different versions transfer at different speeds

12

00:00:32,866 --> 00:00:34,266

The lines used in different versions are also different

14

00:00:37,566 --> 00:00:40,666

The less lines that are used, the slower the transmission speed

16

00:00:42,800 --> 00:00:44,500

The more wires used, the faster he transfers

18

00:00:46,800 --> 00:00:49,566

Generally we call it throughput

19

00:00:50,066 --> 00:00:52,566

There are X1, X4, X8, X16 in this version

twenty two

00:00:55,466 --> 00:00:59,300

X16 represents lines with 16 groups and 32 lines

twenty four

00:01:01,033 --> 00:01:02,800

The more lines and the higher the version, the more data he sends out every second

27

00:01:07,066 --> 00:01:08,233

The PCIe management module contains reset, clock and data

30

00:01:13,233 --> 00:01:14,833

In the Apple mobile phone, the CPIe bus is mainly used in the circuit from the CPU to the wifi

33

00:01:21,466 --> 00:01:22,900

CPU to hard disk, CPU to baseband circuit

35

00:01:25,233 --> 00:01:28,833

The amount of data required by these circuits is very large, so they use the PCIe bus

37

00:01:32,166 --> 00:01:33,800

Next, we will take the Qualcomm model of iPhone x as an example to find the PCIe bus between the CPU and the hard disk.

41

00:01:42,266 --> 00:01:45,333

We first find the hard disk in the annotation diagram

42

00:01:45,766 --> 00:01:48,466

Go to the drawing to search for the hard disk location number

43

00:01:52,700 --> 00:01:54,000

After finding the hard disk, we can look at the lines around the hard disk

46

00:01:59,833 --> 00:02:04,033

The one that identifies PCIe is the PCIe bus from the hard disk to the CPU

47

00:02:04,666 --> 00:02:06,800

In this line we can see that the PCIe bus has a set of clocks

49

00:02:11,400 --> 00:02:13,333

The clock is directly connected to the CPU

51

00:02:17,233 --> 00:02:19,033

There are two other groups of data RX reception and TX transmission of the PCIe bus

53

00:02:24,266 --> 00:02:26,233

The data line has a characteristic

54

00:02:26,433 --> 00:02:28,900

They all pass through the coupling capacitor first, and then connect to the cpu

56

00:02:33,533 --> 00:02:37,666

This bus is similar to the LPDP bus of the camera, and a coupling capacitor is connected in the middle

58

00:02:40,433 --> 00:02:43,033

If the coupling capacitor is connected to the line, it generally means that the data volume of this line is very large.

61

00:02:47,633 --> 00:02:49,600

It will transmit the signal through the coupling capacitor

63

00:02:50,966 --> 00:02:52,800

If there is a problem with the PCIe bus, it will cause the corresponding function to be unavailable

65

00:02:55,400 --> 00:02:59,066

For example, if the PCIe bus from the hard disk to the CPU is disconnected, the CPU cannot read the hard disk.

67

00:03:01,666 --> 00:03:03,500

resulting in no boot

68

00:03:03,766 --> 00:03:06,433

That's all for this video
