iphone mobile phone commonly used bus

2

00:00:03,433 --> 00:00:07,233

In this video we mainly explain the UART bus

3

00:00:07,700 --> 00:00:10,900

The UART bus is a universal asynchronous transceiver bus

4

00:00:11,666 --> 00:00:14,766

Asynchronous means that data can be transmitted synchronously without additional clock lines

6

00:00:17,666 --> 00:00:20,100

The main function of the UART bus is to convert the signal to be transmitted between serial communication and parallel communication

9

00:00:27,400 --> 00:00:30,966

The serial bus means that when a chip sends data to another chip, it sends it serially in time.

12

00:00:38,500 --> 00:00:41,433

Then this is serial data

13

00:00:41,766 --> 00:00:43,800

Parallel data means that a lot of data can be transmitted simultaneously from chip to chip

16

00:00:48,866 --> 00:00:51,866

Simultaneous transmission is called parallel data

17

00:00:52,266 --> 00:00:53,733

UART bus converts parallel data into serial data

20

00:00:56,600 --> 00:01:00,100

Or convert serial data to parallel data

twenty one

00:01:00,800 --> 00:01:03,400

The UART bus consists of two wires

twenty two

00:01:03,466 --> 00:01:05,400

One is to receive RX and the other is to transmit TX

twenty four

00:01:08,100 --> 00:01:10,466

We can see according to the iPhone mobile phone bus architecture

26

00:01:12,066 --> 00:01:16,466

The UART bus is used between the CPU and the Bluetooth WIFI

27

00:01:16,800 --> 00:01:20,200

The UART bus is used between the CPU and the baseband

28

00:01:20,566 --> 00:01:22,466

Next, let's find out the UART bus between the CPU and WIFI

30

00:01:25,900 --> 00:01:28,200

Let's take the iPhone X as an example, the search method for other models is the same

32

00:01:31,933 --> 00:01:33,200

Because WIFI has few pins, we start to search from WIFI

34

00:01:35,800 --> 00:01:38,300

Find the WIFI location number in the marked map

36

00:01:40,900 --> 00:01:44,500

Then go to the drawing to search for the location number of WIFI

37

00:01:45,900 --> 00:01:47,800

After searching for the WIFI location number, we can look at the line

39

00:01:49,966 --> 00:01:50,966

The English logo UART represents the UART bus from WIFI to CPU

41

00:01:56,733 --> 00:01:57,833

The English logo UART_WLAN_TO_AP indicates that the line is the UART bus from WIFI to CPU

45

00:02:07,600 --> 00:02:09,300

By looking at the bitmap, we can find that

47

00:02:11,433 --> 00:02:14,633

The signal is directly connected to the CPU by WIFI, and there is no fuse resistor in the middle

49

00:02:17,633 --> 00:02:20,133

If there is a problem with this UART bus, it will prompt that the WIFI password is wrong

53

00:02:25,400 --> 00:02:27,966

Even if the password entered is correct, he will prompt an error

55

00:02:29,533 --> 00:02:30,666

In this case, the UART bus from WIFI to CPU is disconnected.

57

00:02:35,466 --> 00:02:37,166

Next, let's look for the UART bus between the CPU and the baseband

59

00:02:42,433 --> 00:02:45,033

We first find the baseband position number in the annotation diagram

61

00:02:46,766 --> 00:02:49,366

Go to the drawing to search for the baseband position number

62

00:02:50,433 --> 00:02:52,533

According to the English outside the frame diagram

63

00:02:52,766 --> 00:02:55,533

The one that identifies UART represents the UART bus of the baseband to the CPU

65

00:02:59,166 --> 00:03:04,900

In the current page, the identification UART_BB_TO_AOP_RXD is the reception of the UART bus of the baseband to the CPU

67

00:03:10,366 --> 00:03:12,466

He is the baseband directly connected to the CPU

68

00:03:13,266 --> 00:03:17,166

The signal below is UART_AOP_TO_BB_TXD, indicating that it is the transmit signal from the CPU to the baseband

70

00:03:23,333 --> 00:03:25,533

It is also directly connected to the baseband by the CPU

71

00:03:26,700 --> 00:03:29,500

That's all for this video
