Difference between good and bad bottom of iPhone motherboard

2

00:00:03,133 --> 00:00:06,566

In this video, we mainly explain the function of the bottom of the board and the structure of the bottom of the board.

4

00:00:08,900 --> 00:00:09,700

The bottom of the board is also called the bottom of the PCB in actual maintenance.

9

00:00:20,433 --> 00:00:22,200

Its main function is to support electronic components

11

00:00:24,666 --> 00:00:26,166

To put it simply,

12

00:00:26,533 --> 00:00:28,933

Electronic components are soldered to the bottom of the PCB

15

00:00:34,600 --> 00:00:38,466

The lines will be connected by board layer traces

16

00:00:38,666 --> 00:00:41,733

Here is a picture of the bottom of the PCB board

17

00:00:42,333 --> 00:00:43,333

We can see that

18

00:00:43,533 --> 00:00:46,866

There are many thin lines on the bottom of the board

19

00:00:47,133 --> 00:00:49,933

When we solder the components to it

20

00:00:49,966 --> 00:00:51,166

The signals will be connected through these traces on the bottom of the board.

twenty two

00:00:55,400 --> 00:00:57,000

PCB bottom structure

twenty three

00:00:57,133 --> 00:01:01,800

From the earliest single-layer wiring to double-layer wiring on the bottom of the board

twenty four

00:01:02,000 --> 00:01:05,166

Single-layer wiring means that only one layer of wiring is printed on the surface of the PCB.

26

00:01:07,766 --> 00:01:08,600

Double-sided means that the circuit is also printed on the reverse side of the PCB

28

00:01:11,966 --> 00:01:13,733

With the advancement of technology, the two-layer wiring can no longer meet the demand

30

00:01:17,333 --> 00:01:19,800

So now it has developed to multi-layer routing

31

00:01:20,100 --> 00:01:21,333

Multi-layer wiring refers to the fact that many layers of lines are routed inside the PCB board layer.

33

00:01:24,733 --> 00:01:27,533

The number of lines inside the PCB board layer is determined according to the design of the electronic product

35

00:01:30,866 --> 00:01:34,066

For example, the current notebook motherboards and mobile phone motherboards generally have 8-12 layers of internal circuits.

37

00:01:37,333 --> 00:01:40,500

The number of layers of lines used by different models is also different

39

00:01:41,500 --> 00:01:43,466

Next, let's take a look at what the actual board layer looks like.

41

00:01:44,300 --> 00:01:46,400

The ply is actually very thin

42

00:01:46,533 --> 00:01:48,566

After zooming in we can see

43

00:01:48,666 --> 00:01:50,733

This ply is very thin

44

00:01:50,800 --> 00:01:52,533

But inside such a thin board, it can run 8-12 layers of lines

46

00:01:55,166 --> 00:01:57,733

We can see when we scrape the side of the ply

48

00:01:59,300 --> 00:02:01,700

There will be a lot of copper wires on the side of the board

49

00:02:01,700 --> 00:02:05,766

These copper wires refer to the board layer traces

50

00:02:09,066 --> 00:02:10,200

This is the layer routing of the Apple mobile phone motherboard

52

00:02:12,466 --> 00:02:14,133

Let's take the iPhone 11 as an example to check its layer routing

55

00:02:19,733 --> 00:02:21,566

Open the board layer wiring diagram, we can see the number of different layers

58

00:02:23,600 --> 00:02:26,433

Each layer is marked with a different color

59

00:02:26,533 --> 00:02:27,800

The lines on these layers connect the electronic components

62

00:02:30,333 --> 00:02:33,333

These lines belong to the PCB board and are called internal wiring.

63

00:02:33,933 --> 00:02:36,600

This lesson we learn here
