1

00:00:00,566 --> 00:00:03,333

Distinction between good and bad iPhone mainboards

2

00:00:03,666 --> 00:00:04,700

In this video,

3

00:00:04,700 --> 00:00:08,800

we mainly identify which mainboards in the iPhone mainboards are relatively poor

4

00:00:10,233 --> 00:00:14,466

iPhones of the same series will use mainboards from different manufacturers

5

00:00:18,233 --> 00:00:21,400

Some batches of these mainboards will have some problems

6

00:00:22,800 --> 00:00:25,233

When we solder, there may be a layer break

7

00:00:28,000 --> 00:00:29,400

In iPhone 6 series,

8

00:00:29,600 --> 00:00:32,566

the mainboard produced by UMT is relatively poor,

9

00:00:33,900 --> 00:00:37,300

and the board layer is prone to disconnection during soldering

10

00:00:37,533 --> 00:00:39,033

In the 6s series,

11

00:00:39,166 --> 00:00:42,200

the main board produced by OPC is relatively poor,

12

00:00:42,900 --> 00:00:46,366

and the board layer is prone to disconnection during soldering

13

00:00:46,800 --> 00:00:48,300

In the iPhone 8 series,

14

00:00:48,400 --> 00:00:51,333

the mainboard numbered H3 K5 is the worst

15

00:00:52,066 --> 00:00:53,800

After the air gun is welded,

16

00:00:54,133 --> 00:00:57,000

it will cause a large area of 鈥嬧€媡he board to break

17

00:00:58,566 --> 00:01:00,800

Among the iPhone 8p series,

18

00:01:00,933 --> 00:01:05,400

the mainboard with batch PC-V0 produced by MRS is the worst

19

00:01:05,766 --> 00:01:09,800

After soldering, there will be multiple disconnections on the board layer

20

00:01:10,966 --> 00:01:13,733

Like the 8th generation and 8p series,

21

00:01:14,033 --> 00:01:16,200

you must pay attention when repairing,

22

00:01:16,733 --> 00:01:18,333

if you don't pay attention,

23

00:01:18,533 --> 00:01:21,100

it may cause the machine not to be turned on

24

00:01:21,466 --> 00:01:23,333

For iPhone x and above models,

25

00:01:23,666 --> 00:01:26,700

the mainboard produced by MRS is relatively poor,

26

00:01:27,000 --> 00:01:29,400

and there will be disconnection occasionally,

27

00:01:31,166 --> 00:01:33,133

but compared with the previous series,

28

00:01:33,433 --> 00:01:36,500

the probability of disconnection will be much smaller

29

00:01:40,566 --> 00:01:43,666

Next, let's go to check the rubbish mainboard of each model

30

00:01:46,966 --> 00:01:50,033

Let's take a look at the rubbish mainboard of the iPhone 6

31

00:01:51,500 --> 00:01:54,800

The 6-series rubbish mainboard is made by UMT

32

00:01:54,966 --> 00:01:57,766

It may cause the board layer to break when soldering

33

00:01:58,633 --> 00:02:00,433

Pay attention to it when repairing

34

00:02:05,233 --> 00:02:08,900

The 6s series of rubbish mainboard is made by OPC,

35

00:02:09,466 --> 00:02:12,266

and the board layer may be disconnected during welding

36

00:02:13,166 --> 00:02:15,133

Pay attention to it when repairing

37

00:02:16,900 --> 00:02:20,300

We must pay attention when repairing the iPhone 8 mainboard

38

00:02:20,300 --> 00:02:23,166

marked with the batch number H3 K5

39

00:02:24,266 --> 00:02:27,700

The blowing of the air gun will cause disconnection of the board,

40

00:02:31,066 --> 00:02:32,966

especially the audio position

41

00:02:33,766 --> 00:02:35,833

There will be about 20 disconnections

42

00:02:36,566 --> 00:02:39,033

So, Never solder the audio position

43

00:02:40,666 --> 00:02:43,733

What else positions of this mainboard cannot be welded?

44

00:02:44,933 --> 00:02:48,333

The area between the WIFI and the hard disk cannot be welded

45

00:02:49,333 --> 00:02:53,766

The side can be welded, and the lower side of the hard disk can be welded

46

00:02:56,366 --> 00:02:58,766

Rubbish mainboard for iPhone 8p

47

00:02:59,366 --> 00:03:04,366

We must pay attention when repairing the mainboard marked with the batch number PC-V0,

48

00:03:05,300 --> 00:03:09,000

otherwise it is easy to cause low current to no booting

49

00:03:10,233 --> 00:03:15,100

The disconnection position of the 8p is similar to that of the 8th generation

50

00:03:16,166 --> 00:03:18,033

They are all at the audio position,

51

00:03:18,266 --> 00:03:20,500

and about 20 wires will be broken

52

00:03:21,333 --> 00:03:23,000

There is no way to repair

53

00:03:23,300 --> 00:03:26,066

If you want to repair, you can only move the board

54

00:03:27,100 --> 00:03:29,700

Chips at the top or bottom can be soldered

55

00:03:31,766 --> 00:03:34,166

Ok, this is the end of the knowledge points

56

00:03:34,166 --> 00:03:37,233

on the distinction between good and bad iPhone motherboards
