1

00:00:00,800 --> 00:00:03,866

In this lesson we're going to learn about the main audio

2

00:00:04,600 --> 00:00:09,733

In Apple's models, most audio chips are made by a single manufacturer

3

00:00:10,266 --> 00:00:12,533

The main audio is mainly responsible for

4

00:00:12,533 --> 00:00:16,666

converting digital audio signals into analog audio signals,

5

00:00:17,066 --> 00:00:21,366

or converting analog audio signals into digital audio signals

6

00:00:22,066 --> 00:00:26,333

In mobile phones, it is mainly used to process sound circuits

7

00:00:26,833 --> 00:00:31,833

For example, the voice we speak when we make a phone call is an analog signal,

8

00:00:33,166 --> 00:00:35,800

and the music we play is a digital signal

9

00:00:37,600 --> 00:00:41,433

Circuit signal conversion is mainly controlled by the main audio

10

00:00:42,866 --> 00:00:47,500

In the mainboard, audio surface for glass crystal, relatively bright,

11

00:00:47,500 --> 00:00:49,200

most of the rectangle

12

00:00:52,733 --> 00:00:55,866

Its surface usually begins with 338s

13

00:00:56,266 --> 00:00:59,333

Damage to the master audio will result in no sound,

14

00:00:59,866 --> 00:01:03,666

no message, no receiver, no ringtone

15

00:01:04,200 --> 00:01:08,000

Problems like these can be caused by large audio damage

16

00:01:09,000 --> 00:01:10,866

After large audio damage,

17

00:01:11,066 --> 00:01:14,266

the replacement needs to be replaced with the same model

18

00:01:14,800 --> 00:01:18,766

Then let's go to the physical mainboard to find a few main audio to know

19

00:01:20,333 --> 00:01:23,033

Audio chip is also called master audio

20

00:01:23,766 --> 00:01:25,833

This is the iPhone 7 mainboard

21

00:01:26,533 --> 00:01:29,633

Its audio chip is located in the middle of the mainboard,

22

00:01:30,000 --> 00:01:34,066

the surface is very bright, the shape is generally rectangular

23

00:01:35,333 --> 00:01:37,666

This mainboard is a XR model,

24

00:01:38,066 --> 00:01:42,133

and its audio chip is located in the upper right corner of the power supply

25

00:01:43,200 --> 00:01:48,500

This chip also looks big, with a logo beginning with 338s

26

00:01:49,500 --> 00:01:51,066

This is the main audio

27

00:01:52,166 --> 00:01:55,833

This mainboard is 11 mainboard, double-layer mainboard

28

00:01:56,666 --> 00:01:59,933

The audio chip is generally located in the upper board

29

00:02:00,266 --> 00:02:03,400

The mainboard's audio chip is located next to the power supply

30

00:02:05,133 --> 00:02:07,033

The surface of this chip is bright,

31

00:02:07,433 --> 00:02:09,300

the font is not very clear,

32

00:02:11,266 --> 00:02:13,400

it is the audio chip main audio

33

00:02:14,933 --> 00:02:16,866

So that's all for this lesson
