1

00:00:00,800 --> 00:00:03,900

In this video we're going to learn about the NFC chips

2

00:00:05,833 --> 00:00:08,600

NFC stands for Near Field Communication,

3

00:00:08,833 --> 00:00:12,300

sometimes it's called Near Field Wireless communication

4

00:00:13,000 --> 00:00:18,300

It belongs to a short distance high frequency wireless transmission communication technology

5

00:00:18,766 --> 00:00:23,066

It means that non-contact wireless data transmission can be carried out

6

00:00:23,066 --> 00:00:27,300

when the distance between electronic devices is less than 20 centimeters

7

00:00:28,333 --> 00:00:31,400

NFC technology is widely used in our daily life

8

00:00:33,700 --> 00:00:36,666

For example, we swipe our bus card

9

00:00:37,700 --> 00:00:41,666

When SF Express mail, you need to register your ID card,

10

00:00:41,933 --> 00:00:45,133

you just need to hold your ID card near this device

11

00:00:45,566 --> 00:00:48,966

The ID information will be recognized inside the device

12

00:00:50,366 --> 00:00:52,733

These are all using NFC technology

13

00:00:53,866 --> 00:00:58,700

In Apple's models, NFC chips have been used since the iPhone 6

14

00:01:00,500 --> 00:01:05,300

There is only one NFC chip in the mainboards of the iPhones from 6 to 11

15

00:01:05,566 --> 00:01:09,533

But when it comes to the iPhone 12, there are two NFC chips

16

00:01:10,166 --> 00:01:13,700

In actual maintenance, when the NFC chip is damaged,

17

00:01:14,600 --> 00:01:16,733

it leads to two common problems

18

00:01:17,100 --> 00:01:20,700

The first is that it cannot be activated after brushing

19

00:01:22,000 --> 00:01:25,200

The second one is, when we dropped the phone,

20

00:01:25,866 --> 00:01:29,233

the last one get stuck when we try to enter the password

21

00:01:29,933 --> 00:01:32,500

The CPU does not recognize the NFC,

22

00:01:32,766 --> 00:01:34,766

or the NFC chip is damaged

23

00:01:38,266 --> 00:01:43,466

The NFC function is damaged and the possibility of repair is not very high

24

00:01:44,666 --> 00:01:46,733

But both problems can be fixed

25

00:01:47,733 --> 00:01:52,966

The NFC chip is bound to the CPU and needs to be replaced with the same model

26

00:01:54,100 --> 00:01:58,333

After replacement, the two common problems can be fixed

27

00:02:01,266 --> 00:02:03,733

But the NFC function cannot be fixed,

28

00:02:04,266 --> 00:02:06,933

because the NFC chip is bound to the CPU,

29

00:02:07,566 --> 00:02:11,266

and there is only one corresponding NFC chip for per machine

30

00:02:14,466 --> 00:02:16,666

When we repair the iPhone in the future,

31

00:02:17,100 --> 00:02:19,733

we will only repair the failure to activate

32

00:02:20,300 --> 00:02:23,366

and failure of stucking on the enter password surface

33

00:02:24,600 --> 00:02:28,633

Early NFC chips were thick, with a black surface

34

00:02:30,766 --> 00:02:34,300

Later chips were thinner and made of glass crystals

35

00:02:35,733 --> 00:02:38,633

Let's get to know the NFC chip in the real object

36

00:02:39,500 --> 00:02:41,700

This mainboard is an iPhone 6 mainboard,

37

00:02:42,333 --> 00:02:44,733

and its NFC chip is in this position

38

00:02:45,800 --> 00:02:49,233

Model number we can see, 65V10

39

00:02:50,000 --> 00:02:52,600

This mainboard is an iPhone 7 mainboard,

40

00:02:53,033 --> 00:02:55,633

and its NFC chip is in this position

41

00:02:56,000 --> 00:02:59,566

The chip's model number is 67V04

42

00:03:00,433 --> 00:03:02,666

This mainboard is an iPhone 8 mainboard,

43

00:03:03,300 --> 00:03:08,533

its NFC chip is in this position, the model number is 80VES

44

00:03:10,166 --> 00:03:12,300

This board is a XR board,

45

00:03:13,100 --> 00:03:15,766

and its NFC chip is in this position

46

00:03:16,533 --> 00:03:19,800

The model of the NFC chip is not easy to identify

47

00:03:21,166 --> 00:03:24,166

This mainboard is the lower mainboard of the iPhone 11,

48

00:03:24,866 --> 00:03:27,933

and its NFC chip is in this position

49

00:03:28,500 --> 00:03:31,866

The chip is black, and you can't see the model number on it

50

00:03:34,600 --> 00:03:36,633

So that's all for this lesson
