1

00:00:00,633 --> 00:00:03,700

In this lesson we're going to learn about the fast charge chip

2

00:00:04,533 --> 00:00:08,866

In Apple's mainboard, the fast charge chip is a charging voltage detection chip

3

00:00:09,666 --> 00:00:11,500

It has no charging function

4

00:00:13,066 --> 00:00:17,433

It mainly recognizes whether the charger voltage supports fast charging

5

00:00:19,066 --> 00:00:22,233

If it recognizes that the charger supports fast charging,

6

00:00:22,400 --> 00:00:26,900

it will notify the charging chip and make the charging chip enter the fast charging mode

7

00:00:28,300 --> 00:00:30,900

After the charging chip enters the fast charging mode,

8

00:00:31,200 --> 00:00:34,166

it will make the charging circuit produce large current,

9

00:00:34,566 --> 00:00:37,033

then realize the fast charging function

10

00:00:37,400 --> 00:00:41,500

Apple's models don't support fast charging until the iPhone 8 and up

11

00:00:43,600 --> 00:00:48,066

So from the iPhone 8 and above mainboards, we can find the fast charge chip

12

00:00:49,866 --> 00:00:53,866

After the fast charge is damaged, it will lead to slow charging,

13

00:00:54,266 --> 00:00:58,866

no charging, and sometimes it will lead to the error of brushing machine

14

00:00:59,266 --> 00:01:02,400

The replacement needs to be replaced with the same model

15

00:01:06,133 --> 00:01:12,133

On mainboards, common logos start with CG87 or CG88

16

00:01:15,033 --> 00:01:18,766

Next, let's get to know the fast charge chip in real life

17

00:01:20,766 --> 00:01:23,000

The mainboard is an iPhone 8p mainboard,

18

00:01:23,266 --> 00:01:26,233

and its fast charge chip is located above the hard drive

19

00:01:27,266 --> 00:01:29,000

This is the fast charge chip

20

00:01:29,766 --> 00:01:32,333

This mainboard is an iPhone XR mainboard,

21

00:01:32,800 --> 00:01:36,000

and its fast charge chip is in the lower left of the CPU

22

00:01:37,133 --> 00:01:39,633

This chip is the XR fast charging chip

23

00:01:40,200 --> 00:01:42,566

This mainboard is an iPhone 11 mainboard,

24

00:01:42,766 --> 00:01:45,366

and its fast charge chip is inside the shield

25

00:01:45,733 --> 00:01:50,166

With the top cover removed, this chip is the iPhone 11's fast charge chip

26

00:01:51,000 --> 00:01:53,000

So that's all for this lesson
