1

00:00:00,800 --> 00:00:04,533

In this lesson, we're going to learn the ACC power supply chips

2

00:00:05,900 --> 00:00:07,333

In Apple models,

3

00:00:07,633 --> 00:00:11,066

the ACC power supply chip is mainly used to convert the battery power

4

00:00:11,066 --> 00:00:14,100

into the operating voltage of the USB device

5

00:00:18,166 --> 00:00:21,433

For example, the mobile phone has the charge function

6

00:00:21,800 --> 00:00:23,933

When my mobile phone is out of power,

7

00:00:24,200 --> 00:00:25,933

after connecting the charger line,

8

00:00:26,066 --> 00:00:28,433

your mobile phone can charge my mobile phone

9

00:00:29,933 --> 00:00:35,366

The power supply received by my mobile phone is converted from ACC power supply by USB chip

10

00:00:36,300 --> 00:00:40,300

In early models, the ACC was powered by the mains,

11

00:00:41,133 --> 00:00:43,766

and the phone charged slowly during charging

12

00:00:45,933 --> 00:00:50,400

From iPhone xs models, there will be a separate ACC-powered chip

13

00:00:52,233 --> 00:00:56,333

With a separate ACC powered chip, the phone will charge faster

14

00:00:58,333 --> 00:01:00,400

For example, in the summer,

15

00:01:01,766 --> 00:01:05,366

we insert a small fan in the tail socket of the mobile phone,

16

00:01:05,500 --> 00:01:06,800

the fan can turn

17

00:01:09,266 --> 00:01:15,500

The power supply of this fan is output to the fan after the ACC power supply is converted by the USB chip

18

00:01:16,933 --> 00:01:20,200

With ACC power chip, the fan speed is faster

19

00:01:22,966 --> 00:01:27,500

Without ACC power chip, its speed will be relatively small

20

00:01:28,966 --> 00:01:34,366

Because in the early model, the power supply of ACC was output by the power supply,

21

00:01:34,566 --> 00:01:36,633

and the power was relatively small

22

00:01:37,100 --> 00:01:41,533

The ACC chip will only be available on models from the iPhone xs

23

00:01:42,433 --> 00:01:44,866

The chip has a black, square surface

24

00:01:47,466 --> 00:01:50,933

It is not easy for us to identify in real objects,

25

00:01:51,433 --> 00:01:55,400

so we need to use the circuit diagarm or the component map to identify

26

00:01:55,933 --> 00:01:59,533

After it is damaged, it will lead to no connection,

27

00:01:59,633 --> 00:02:01,766

no charging and other faults

28

00:02:03,100 --> 00:02:06,366

When repairing, we need the same model to replace

29

00:02:06,800 --> 00:02:10,233

Let's go to the physical mainboard to know the ACC power supply chip

30

00:02:11,966 --> 00:02:14,100

This mainboard is a XR mainboard,

31

00:02:14,500 --> 00:02:17,366

and its ACC power chip is on the Wifi

32

00:02:19,000 --> 00:02:22,100

This chip is the ACC power supply chip of XR

33

00:02:23,700 --> 00:02:25,766

The mainboard is a xr Max mainboard,

34

00:02:26,233 --> 00:02:28,733

and its ACC powered chip is inside the shield

35

00:02:31,000 --> 00:02:32,633

After we remove the shield,

36

00:02:32,933 --> 00:02:34,866

this chip is the ACC power chip

37

00:02:36,366 --> 00:02:38,900

This mainboard is the mainboard of iPhone 11,

38

00:02:39,233 --> 00:02:43,666

and its ACC powered chip is located on the reverse side of the upper layer

39

00:02:44,800 --> 00:02:47,733

This chip is the ACC power supply chip of 11

40

00:02:49,566 --> 00:02:51,733

So that's it for this lesson
