1

00:00:00,400 --> 00:00:03,433

In this lesson we're going to learn about the gyro chip

2

00:00:04,700 --> 00:00:07,733

Gyro is also called angular velocity sensor

3

00:00:08,166 --> 00:00:11,866

A gyro is a device used to sense and maintain direction

4

00:00:13,100 --> 00:00:18,833

In the iPhone, the common functions, such as lift and wake up, gradienter,

5

00:00:19,066 --> 00:00:22,033

automatic landscape and portrait screen,

6

00:00:22,300 --> 00:00:25,666

and rangefinder, are the use of the gyro chip

7

00:00:26,566 --> 00:00:29,500

The damage of the gyro will lead to many faults,

8

00:00:30,433 --> 00:00:33,933

such as the phone cannot be woken up after the lock screen,

9

00:00:35,100 --> 00:00:39,333

and the direction will not change when playing games that need to turn the phone,

10

00:00:39,466 --> 00:00:41,833

such as racing and shooting games

11

00:00:42,433 --> 00:00:45,466

Such faults can be caused by a damaged gyro

12

00:00:46,833 --> 00:00:49,733

The replacement needs to be replaced with the same model

13

00:00:53,133 --> 00:00:55,766

In the models of iPhone 6s and above,

14

00:00:56,333 --> 00:00:59,300

accelerators are integrated into the gyro chip

15

00:00:59,900 --> 00:01:03,000

This chip is mainly used for physical acceleration,

16

00:01:03,166 --> 00:01:05,166

to improve the speed of the phone

17

00:01:06,000 --> 00:01:08,800

Let's go to the physical mainboard to know the gyro chip

18

00:01:11,066 --> 00:01:14,533

The gyro chip will be included in all Apple's mainboards

19

00:01:15,033 --> 00:01:17,333

The mainboard is an iPhone 7 mainboard,

20

00:01:18,066 --> 00:01:21,066

and its gyro chip is under the battery holder

21

00:01:22,066 --> 00:01:24,400

This chip is the iPhone 7's gyro chip

22

00:01:26,066 --> 00:01:28,233

This is the iPhone 8p mainboard,

23

00:01:28,866 --> 00:01:32,466

and its gyro chip is located in the upper right corner of the hard drive

24

00:01:33,633 --> 00:01:35,900

This chip is the 8p gyro chip

25

00:01:38,133 --> 00:01:40,300

This mainboard is a XR mainboard,

26

00:01:40,800 --> 00:01:44,800

and its gyro chip is located under the wifi, inside the shield

27

00:01:45,000 --> 00:01:48,700

With the shield removed, this chip is the gyro chip

28

00:01:49,266 --> 00:01:51,766

This mainboard is an iPhone 11 mainboard,

29

00:01:52,466 --> 00:01:54,800

and its gyro chip is in the lower mainboard,

30

00:01:55,133 --> 00:01:57,900

located at the bottom of the lower mainboard

31

00:01:58,933 --> 00:02:01,466

This chip is the iPhone 11's gyro chip

32

00:02:03,100 --> 00:02:05,233

So that's all for this lesson
