1

00:00:00,800 --> 00:00:04,300

In this video we're going to learn about the barometric sensors

2

00:00:05,333 --> 00:00:10,533

A barometric sensor is an instrument used to measure the absolute pressure of a gas

3

00:00:11,333 --> 00:00:15,300

In iPhone, it is mainly used to make navigation more accurate

4

00:00:19,333 --> 00:00:23,733

A barometric sensor is a measurement of the pressure of the atmosphere

5

00:00:24,333 --> 00:00:27,300

For example, in the health function of the iPhone,

6

00:00:27,666 --> 00:00:29,266

when we climb a building,

7

00:00:29,833 --> 00:00:32,700

the record will show how many floors we have climbed

8

00:00:33,600 --> 00:00:35,500

How does it calculate the floors?

9

00:00:36,633 --> 00:00:38,766

It just uses a barometric sensor

10

00:00:39,633 --> 00:00:43,400

At different heights, the atmospheric pressure is different

11

00:00:43,866 --> 00:00:45,433

When you go up one floor,

12

00:00:46,633 --> 00:00:49,333

the distance is about 3-4 meters

13

00:00:52,600 --> 00:00:55,300

The pressure in their atmospheres is different,

14

00:00:55,766 --> 00:00:58,266

and barometric sensors can detect that

15

00:00:59,600 --> 00:01:01,766

When the barometric sensor is damaged,

16

00:01:02,166 --> 00:01:04,600

a common failure is the system stalling

17

00:01:05,200 --> 00:01:11,766

For example, the xs or xs max mainboard often encounters a problem in the actual maintenance,

18

00:01:12,500 --> 00:01:15,066

that is, the camera will get stuck

19

00:01:15,833 --> 00:01:19,833

The problem may be caused by a damaged barometric sensor on the tail plug

20

00:01:20,766 --> 00:01:24,033

In iphones, from the iPhone 6 to the iPhone x,

21

00:01:25,033 --> 00:01:27,766

the barometric sensor is located in the mainboard

22

00:01:29,400 --> 00:01:33,833

For models above xs, some of them are in the tail plug cables,

23

00:01:34,866 --> 00:01:37,300

so we can't see the chip in the mainboard

24

00:01:38,766 --> 00:01:42,633

The barometric sensor is a rectangle with a hole in the surface

25

00:01:45,266 --> 00:01:48,400

Now, let's get to know the barometric sensor in the mainboard

26

00:01:49,766 --> 00:01:51,933

The mainboard is an iPhone 6 mainboard,

27

00:01:52,233 --> 00:01:55,533

and its barometric sensor is located near the hard drive

28

00:01:56,700 --> 00:01:58,800

This chip is the barometric sensor

29

00:02:02,233 --> 00:02:04,266

This is an iPhone 7 mainboard,

30

00:02:05,233 --> 00:02:07,566

and its air barometric sensor is at the top

31

00:02:08,900 --> 00:02:11,366

This chip is its barometric sensor

32

00:02:12,900 --> 00:02:17,533

This is the iPhone 8 mainboard, and it has the barometric sensor on the top

33

00:02:19,833 --> 00:02:22,566

This chip is the barometric sensor in the iPhone 8

34

00:02:23,466 --> 00:02:25,300

So that's it for this lesson
