1

00:00:00,166 --> 00:00:01,100

Hello

2

00:00:01,666 --> 00:00:06,066

Let's take a look at the combination of PCH and CPU today

3

00:00:06,400 --> 00:00:14,166

First of all, every time Intel releases a new generation of CPUs, it also releases a corresponding chipset

4

00:00:14,200 --> 00:00:19,566

The detailed PCH and CPU combinations in the notebooks are as follows:

5

00:00:19,566 --> 00:00:24,066

The 5-series chipset is the first PCH from Intel

6

00:00:25,366 --> 00:00:30,500

Its models include HM55, HM57, etc

7

00:00:31,233 --> 00:00:34,266

With Core 1st generation CPU

8

00:00:34,700 --> 00:00:37,733

Such as i3-3350M

9

00:00:38,266 --> 00:00:45,400

Later the 6-series models include HM65, HM67, etc

10

00:00:45,666 --> 00:00:50,266

The 6-series chipset is paired with Core 2nd generation CPU

11

00:00:50,300 --> 00:00:53,100

Such as i3-2310M

12

00:00:53,100 --> 00:01:00,433

The 7 Series models include HM70, HM75, HM76 and more

13

00:01:02,133 --> 00:01:06,900

Then the 7 series PCH is paired with Core 2nd and 3rd CPUs

14

00:01:07,766 --> 00:01:10,300

Such as i3-3110M

15

00:01:11,100 --> 00:01:18,500

Common models of the 8 series chipsets are HM86, HM87, QM87, etc

16

00:01:20,900 --> 00:01:23,533

It is paired with Core 4th generation CPU

17

00:01:23,700 --> 00:01:26,233

Such as i3-4310M

18

00:01:26,933 --> 00:01:29,200

Next is the 9 series

19

00:01:29,200 --> 00:01:32,466

The 9-series chipsets are only used in the desktops

20

00:01:32,833 --> 00:01:35,733

The 9-series chipsets are not used in notebooks

21

00:01:36,133 --> 00:01:38,266

Then it's the 100 series chipsets

22

00:01:39,166 --> 00:01:41,900

Common model is HM170

23

00:01:42,166 --> 00:01:45,833

It is paired with Core 6th and 7th generation processors

24

00:01:45,833 --> 00:01:50,600

After 100-series chipsets, 200-series chipsets were introduced

25

00:01:50,600 --> 00:01:53,366

But it's only used in the desktops

26

00:01:53,933 --> 00:01:57,366

The 200-series chipsets are not used in notebooks

27

00:01:57,600 --> 00:02:01,200

The notebooks directly uses the 300 series chipsets

28

00:02:02,166 --> 00:02:07,566

The 300 series includes HM370, HM375, etc

29

00:02:08,800 --> 00:02:13,466

This kind of chipset is paired with Core 8th and 9th generation processors

30

00:02:13,466 --> 00:02:16,700

Then there are the 400 series chipsets

31

00:02:16,766 --> 00:02:20,533

The 400 series is paired with Core 10th generation CPU

32

00:02:22,000 --> 00:02:26,300

The 500 series is paired with Core 11th generation CPU

33

00:02:27,966 --> 00:02:31,166

This is the architecture of PCH plus CPU

34

00:02:34,333 --> 00:02:37,433

It's about the combination of PCH and CPU

35

00:02:38,600 --> 00:02:41,000

For example HM570

36

00:02:42,233 --> 00:02:48,933

It can only be paired with processors such as Core 11th i3, i5, i7, etc.

37

00:02:48,966 --> 00:02:55,133

It doesn't match the previous Core 1st, 2nd, 3rd, 4th and 5th generation CPUs

38

00:02:55,466 --> 00:02:58,366

This is the combination of PCH and CPU
