1

00:00:00,333 --> 00:00:05,866

Hello everyone, today let's learn about the DMI bus between PCH and CPU

2

00:00:06,666 --> 00:00:08,200

In Intel's chipsets

3

00:00:08,433 --> 00:00:12,800

It is used to connect the communication bus between PCH and CPU

4

00:00:13,200 --> 00:00:17,333

And also it is used to transmit all data except display signals

5

00:00:17,666 --> 00:00:23,733

There are a total of four groups, point-to-point transmission, without any components in the middle

6

00:00:24,433 --> 00:00:31,666

DMI_TXN0 and DMI_TXP0 are a pair of transmitted signal lines

7

00:00:32,233 --> 00:00:39,100

DMI_RXN0 and DMI_RXP0 are a pair of receive signal lines

8

00:00:39,600 --> 00:00:45,700

This is group 0, consisting of a pair of transmit and a pair of receive signals

9

00:00:45,900 --> 00:00:49,433

Sent by the bridge, the CPU is the receiver

10

00:00:49,766 --> 00:00:53,866

Then, the CPU sends it, and the PCH receives it.

11

00:00:54,366 --> 00:00:57,900

When PCH sents, it is received by the CPU

12

00:00:58,500 --> 00:01:02,000

When the CPU sends, it is received by the PCH

13

00:01:02,133 --> 00:01:06,900

In the motherboard, they are transmitted point-to-point through the lines of the motherboard

14

00:01:07,233 --> 00:01:10,400

Direct communication between solder joints through wires

15

00:01:10,600 --> 00:01:12,866

Without any other elements in between

16

00:01:13,300 --> 00:01:17,633

This is the DMI bus, which consists of 16 lines in total
