Hello everyone, today let's learn about the FDI bus between CPU and PCH

2

00:00:06,100 --> 00:00:13,933

The FDI bus is in the Intel chipset and is used to connect the communication bus between the PCH and the CPU

3

00:00:14,333 --> 00:00:22,666

It is only used to transmit display signals, point-to-point one-way transmission, without any components in the middle

4

00:00:23,466 --> 00:00:28,566

There are 4 FDI buses in Intel 6~7 series chipsets

5

00:00:29,100 --> 00:00:34,233

Later, in the Intel 8 series chipsets, there are only 2 groups left

6

00:00:34,566 --> 00:00:40,266

In the later Intel 100 series chipsets, this FDI bus is completely cancelled

7

00:00:41,433 --> 00:00:48,100

From this architecture diagram we can see that the FDI bus is connected between the CPU and PCH

8

00:00:48,866 --> 00:00:53,366

They are one-way transfers, only sent by the CPU to the PCH

9

00:00:53,633 --> 00:00:56,933

Mainly used for PCH output display signal

10

00:00:57,733 --> 00:01:00,533

In Intel 6~7 series chipsets

11

00:01:01,166 --> 00:01:08,400

The display signal of the screen, the display signal of HDMI are both output by the PCH

12

00:01:08,700 --> 00:01:11,000

In Intel 8-series chipset

13

00:01:11,666 --> 00:01:15,500

The screen display signal is directly output by the CPU

14

00:01:16,100 --> 00:01:21,333

Only the display signal of the CRT interface is output by the PCH (bridge)

15

00:01:22,000 --> 00:01:30,133

Its signal source comes from the CPU through the FDI bus to the bridge, and then the bridge to the CRT interface

16

00:01:30,600 --> 00:01:33,066

When we say bridge, we mean PCH

17

00:01:34,000 --> 00:01:41,500

In this circuit diagram, you can see that the FDI bus sent by the CPU to the PCH is directly connected

18

00:01:42,133 --> 00:01:47,166

There are no components connected in the middle, which is called point-to-point transmission

19

00:01:48,166 --> 00:01:51,666

This is the FDI bus between CPU and PCH
