1

00:00:00,966 --> 00:00:01,766

Hello,everyone

2

00:00:01,866 --> 00:00:05,933

Today let's learn about the PCIE bus of PCH

3

00:00:06,933 --> 00:00:13,666

First of all, the PCIE bus line is a high-speed, serial, computer expansion bus standard

4

00:00:14,133 --> 00:00:17,066

It was proposed by Intel in 2001

5

00:00:17,800 --> 00:00:24,600

PCIE bus belongs to high-speed serial point-to-point dual-channel high-bandwidth transmission

6

00:00:25,166 --> 00:00:28,233

There are several interface modes with different speeds

7

00:00:28,533 --> 00:00:36,533

Including X1, X2, X4, X8, X16, etc.

8

00:00:36,700 --> 00:00:46,966

Notebook motherboards usually use PCIE x1 speed to connect network cards and wireless network cards, as well as card readers and other devices

9

00:00:47,633 --> 00:00:51,200

It can also be used to extend other external devices

10

00:00:51,400 --> 00:00:59,966

The structure of the PCIE bus: it is composed of a pair of sending siganl, a pair of receiving signal, and a pair of clocks

11

00:01:00,566 --> 00:01:04,866

The pair of transmit signals are transmitted through two capacitors

12

00:01:05,100 --> 00:01:11,666

These two capacitors are coupling capacitors, which are connected in series in the signal circuit

13

00:01:12,066 --> 00:01:19,866

This pair of receiving signals and this pair of clocks do not need to pass through the coupling capacitor when communicating

14

00:01:20,500 --> 00:01:23,666

This is the characteristic of PCIE bus

15

00:01:24,200 --> 00:01:29,433

So we see that this network card chip also has two coupling capacitors next to it

16

00:01:29,600 --> 00:01:33,500

It is a pair of transmit signals of the PCIE bus

17

00:01:33,633 --> 00:01:40,900

The m.2 interface is usually used to connect a wireless network card, or a solid state drive

18

00:01:41,400 --> 00:01:46,533

When used for wireless network card, it only needs to use PCIE x1

19

00:01:47,066 --> 00:01:51,833

When used for SSDs, it needs to use PCIE x4

20

00:01:52,166 --> 00:01:57,633

This is the common PCIE bus connected to the PCH chip in notebook motherboards
