Hello everyone, today let's learn about the SPI bus

2

00:00:04,766 --> 00:00:08,100

SPI bus is a bus consisting of four lines

3

00:00:08,766 --> 00:00:13,533

Usually used for EC or PCH to read the program in Flash ROM

4

00:00:13,966 --> 00:00:22,766

These four lines are chip select signal, serial data output, serial data input and serial clock

5

00:00:23,733 --> 00:00:32,566

These four lines are respectively on the 1st, 2nd, 5th and 6th pin of this 8-pin Flash chip

6

00:00:33,200 --> 00:00:35,566

Take a look at this pin definition

7

00:00:36,566 --> 00:00:42,900

The first pin is CS#, which is the chip select signal of the SPI bus

8

00:00:43,700 --> 00:00:48,866

The second pin is DO, which is the serial data output of the SPI bus

9

00:00:49,500 --> 00:00:53,066

Pin 5 is the serial data input of the SPI bus

10

00:00:54,133 --> 00:00:59,500

The 6th pin CLK refers to the serial clock of the SPI bus

11

00:01:00,300 --> 00:01:01,933

This is the SPI bus

12

00:01:02,966 --> 00:01:10,166

The other pins of this Flash chip are: Pin 3 WP#, which is the write protection pin of the chip

13

00:01:11,033 --> 00:01:15,266

Pin 4 GND, this is the ground pin of the chip

14

00:01:15,766 --> 00:01:20,766

Pin 7 HOLD#, this is the pause and interrupt signal of the chip

15

00:01:21,033 --> 00:01:32,500

The 8th pin VCC, this is the power supply pin of the chip, the power supply voltage is usually 3.3V or 1.8V

16

00:01:33,133 --> 00:01:36,200

With the increasing capacity of Flash chips

17

00:01:36,533 --> 00:01:40,666

Higher and higher requirements for SPI bus transmission speed

18

00:01:41,566 --> 00:01:45,566

So now there is a SPI bus called 4x speed

19

00:01:45,900 --> 00:01:47,733

Like this UO2

20

00:01:47,766 --> 00:01:53,400

It retains the 1st pin CS# (chip select signal) and the 6th pin CLK (serial clock)

21

00:01:53,600 --> 00:01:58,833

Then redefine the original 5th pin SI (serial data input) signal as IO0

22

00:01:59,300 --> 00:02:03,300

Redefine pin 2 SO (serial data output) as IO1

23

00:02:04,666 --> 00:02:10,166

Then define pin 3 WP# (write protection) as IO2

24

00:02:10,600 --> 00:02:15,166

Redefine pin 7 HOLD# (pause, interrupt) as IO3

25

00:02:15,500 --> 00:02:26,266

Input and output composed of four lines of IO0, IO1, IO2, and IO3, plus chip select signal and clock

26

00:02:26,700 --> 00:02:29,500

This is the quad-speed SPI bus

27

00:02:30,266 --> 00:02:35,433

Its transfer speed is faster than the traditional four-wire SPI bus

28

00:02:36,200 --> 00:02:40,533

Mainly used to meet large-capacity Flash ROM data transmission

29

00:02:41,333 --> 00:02:43,733

Whether it's EC or PCH

30

00:02:44,233 --> 00:02:50,666

It can measure the SPI bus waveform on any line of the SPI bus when reading the Flash ROM

31

00:02:51,566 --> 00:02:54,100

OK,this is the SPI bus
