1

00:00:00,566 --> 00:00:03,966

Hello everyone, today we are going to learn about the screen of laptops

2

00:00:05,266 --> 00:00:10,500

Laptop screens are divided into LCD, LED and OLED screens

3

00:00:13,933 --> 00:00:17,966

The structure of LCD screen and LED screen is basically the same

4

00:00:18,900 --> 00:00:21,066

The difference between them is the backlight

5

00:00:24,566 --> 00:00:29,000

The LCD screen uses cold cathode lamp as the backlight of the screen

6

00:00:30,733 --> 00:00:34,333

The circuit board that drives the cold cathode lamp to emit light,

7

00:00:34,333 --> 00:00:36,800

we call it a high voltage board, or inverter

8

00:00:41,900 --> 00:00:43,733

This kind of lamp has a defect,

9

00:00:43,733 --> 00:00:47,300

that is, after a long time of use, black circles will appear

10

00:00:47,300 --> 00:00:50,166

on both ends of the lamp, which is easy to age

11

00:00:54,133 --> 00:00:57,033

Laptops with this LCD screen will mostly

12

00:00:57,033 --> 00:00:58,866

have a black screen after being dropped,

13

00:01:01,666 --> 00:01:05,666

because the lamp tube is broken, resulting in no backlight

14

00:01:09,266 --> 00:01:11,966

This is the common fault of LCD screen

15

00:01:13,100 --> 00:01:17,266

The LED screen uses LED light strips as the backlight of the screen

16

00:01:31,800 --> 00:01:35,966

This little circuit board that drives the LED light is called a boost circuit

17

00:01:42,233 --> 00:01:46,400

The structures of LCD screen and LED screen are basically the same,

18

00:01:46,666 --> 00:01:48,900

but their backlight modules are different

19

00:01:49,933 --> 00:01:54,066

One uses cold cathode tubes and the other uses LED strips

20

00:01:55,033 --> 00:01:58,266

The OLED screen doesn't have an independent backlight,

21

00:01:58,366 --> 00:02:02,200

it is self-illuminating by driving the liquid crystal through current

22

00:02:02,733 --> 00:02:04,866

This screen has more vivid colors and

23

00:02:04,866 --> 00:02:07,866

is suitable for flexible screens and curved screens

24

00:02:12,933 --> 00:02:17,866

Well, here is the difference between LCD, LED and OLED screens
