1

00:00:00,800 --> 00:00:04,800

Hello everyone, today we will learn about the composition of the laptop screen

2

00:00:05,233 --> 00:00:09,400

The screen of the laptop is mainly composed of a backlight circuit,

3

00:00:09,400 --> 00:00:13,733

a display signal processing circuit and a liquid crystal panel

4

00:00:14,133 --> 00:00:17,333

The LCD panel is the part that displays the signal

5

00:00:18,133 --> 00:00:21,200

The backlight circuit and display signal processing circuit

6

00:00:21,200 --> 00:00:23,833

are on a logic board below the screen

7

00:00:28,333 --> 00:00:32,666

The new logic board is thinner, and the old one is wider

8

00:00:38,466 --> 00:00:41,133

In the backlight circuit, there is a flex cable

9

00:00:41,133 --> 00:00:44,266

connected to the LED backlight inside the laptop screen,

10

00:00:49,166 --> 00:00:51,666

which is mainly used to light up the backlight

11

00:00:52,033 --> 00:00:56,333

If the backlight circuit does not work, it will cause the screen to be dark and black

12

00:00:59,366 --> 00:01:04,000

The display signal processing circuit mainly deals with the display signal

13

00:01:04,000 --> 00:01:06,966

transmitted from the mainboard through the screen line,

14

00:01:06,966 --> 00:01:10,733

and then sent to the liquid crystal panel through the flexible cable,

15

00:01:12,033 --> 00:01:15,633

so that the liquid crystal panel displays the processed image.

16

00:01:19,233 --> 00:01:22,133

Well, this is the composition of the laptop screen
