1

00:00:00,566 --> 00:00:03,833

Hello everyone, today we will learn about the laptop battery

2

00:00:09,600 --> 00:00:16,233

Common laptop batteries include 18650 lithium batteries and lithium polymer batteries

3

00:00:18,733 --> 00:00:21,966

In a laptop, the main function of the battery is to provide

4

00:00:21,966 --> 00:00:24,766

a long-lasting battery life for the laptop

5

00:00:37,266 --> 00:00:42,833

The battery consists of a control board, a combination of battery cells and a shell

6

00:00:50,566 --> 00:00:53,900

Laptop batteries are composed of multiple cells

7

00:00:53,900 --> 00:00:57,033

through different parallel and series connections.

8

00:01:00,733 --> 00:01:08,200

For 18650 lithium battery, the voltage of each cell is 3.6V or 3.7V

9

00:01:14,933 --> 00:01:18,933

The charging voltage of a single cell is 4.2V

10

00:01:21,066 --> 00:01:25,766

Like this, it is three batteries in series, and then another group in parallel,

11

00:01:26,600 --> 00:01:29,200

this is called three series two parallel

12

00:01:32,866 --> 00:01:36,266

After connecting in series, its voltage will increase,

13

00:01:36,500 --> 00:01:41,800

and after three batteries are connected in series, it is 11.1V

14

00:01:42,900 --> 00:01:45,000

If we want to charge this battery pack,

15

00:01:45,000 --> 00:01:48,166

we need a voltage above 12.6V,

16

00:01:50,300 --> 00:01:53,000

because these are three cells in series

17

00:01:56,933 --> 00:02:01,800

So series can increase the voltage, parallel can increase the capacity

18

00:02:04,133 --> 00:02:09,600

For the number 18650, 18 means its diameter is 18mm,

19

00:02:09,766 --> 00:02:15,466

65 means its length is 65mm, and 0 means it is cylindrical

20

00:02:23,200 --> 00:02:26,333

So that we call it 18650

21

00:02:26,933 --> 00:02:32,100

The disadvantage of this kind of battery is that it's not suitable for ultrabooks

22

00:02:33,033 --> 00:02:34,833

Because its volume is fixed

23

00:02:37,733 --> 00:02:41,533

Well, this is the introduction of 18650 battery,

24

00:02:43,566 --> 00:02:46,233

let's take a look at the lithium polymer battery

25

00:02:51,766 --> 00:02:53,633

it is a kind of chemical battery

26

00:02:54,433 --> 00:02:58,800

It has the advantages of high energy density, no leakage,

27

00:02:58,800 --> 00:03:02,866

good impact resistance, miniaturization and light weight

28

00:03:03,333 --> 00:03:06,933

This battery has no standard capacity, no standard size

29

00:03:07,400 --> 00:03:10,833

It can be built according to the space inside the machine

30

00:03:12,166 --> 00:03:16,466

Its thickness can be as small as 0.4 mm or less

31

00:03:17,166 --> 00:03:21,166

So this lithium polymer battery is suitable for ultrabooks
