1

00:00:00,366 --> 00:00:03,933

Today we are going to learn about solid state drives of laptops

2

00:00:06,933 --> 00:00:10,200

Solid state drive is abbreviated as SSD

3

00:00:12,200 --> 00:00:16,766

It is a hard disk made of an array of solid-state electronic memory chips

4

00:00:19,400 --> 00:00:24,300

Solid state drives in laptops can be divided into four types by interfaces

5

00:00:25,233 --> 00:00:31,533

The first is SATA interface hard drives, inserted in the mainboard SATA interface

6

00:00:36,366 --> 00:00:39,666

The second type is the hard disk with the M.2 interface

7

00:00:40,333 --> 00:00:43,833

The third type is the mSATA interface hard disk

8

00:00:44,600 --> 00:00:48,800

There are also onboard solid state drives that soldered directly to the mainboard

9

00:00:49,466 --> 00:00:55,766

This SATA interface solid state disk, its appearance is very similar with the hard disk drive

10

00:00:56,433 --> 00:00:59,633

They are inserted in the mainboard SATA interface above,

11

00:00:59,766 --> 00:01:02,066

through the SATA bus communication

12

00:01:02,566 --> 00:01:06,033

The data is stored on the chip, and if the chip is damaged,

13

00:01:06,433 --> 00:01:09,100

the data will be lost in a devastating way

14

00:01:10,366 --> 00:01:13,233

We call these memory chips flash memory chips

15

00:01:13,933 --> 00:01:18,066

The master chip is responsible for managing these flash memory chips

16

00:01:19,866 --> 00:01:23,633

Ok, let's take a look at the mSATA interface SSD

17

00:01:24,466 --> 00:01:29,466

The mSATA interface has the same appearance as the MINI PCIE slot

18

00:01:30,966 --> 00:01:35,566

However, MINI PCIE slots are distributed on the PCIE bus,

19

00:01:36,200 --> 00:01:40,500

while mSATA ports use the SATA bus

20

00:01:41,033 --> 00:01:44,766

This is a solid state drive with mSATA interface

21

00:01:45,200 --> 00:01:48,466

Let's take a look at the M.2 interface SSD

22

00:01:49,300 --> 00:01:51,866

M.2 Interfaces are of two types:

23

00:01:54,033 --> 00:02:00,000

one is distributed with a SATA bus and the other is distributed with a PCIE bus

24

00:02:01,366 --> 00:02:05,900

The NVME protocol uses the PCIE bus for communication

25

00:02:08,400 --> 00:02:12,433

SATA bus communication is the SATA protocol

26

00:02:13,200 --> 00:02:19,066

In terms of speeds, the NVME protocol is much faster than the SATA bus

27

00:02:24,666 --> 00:02:27,000

As can be seen from the interface type,

28

00:02:27,533 --> 00:02:31,233

the one with two error prevention interfaces is SATA,

29

00:02:31,866 --> 00:02:36,166

and the one with only one error prevention interface is NVME

30

00:02:39,100 --> 00:02:41,566

There is also a mainboard similar to this Apple,

31

00:02:43,633 --> 00:02:46,800

it is directly welded to the hard disk chip on the mainboard,

32

00:02:50,300 --> 00:02:52,433

this chip is not easy to replace

33

00:02:55,066 --> 00:02:58,366

Ok, this is the introduction of the solid state drives
