1

00:00:01,333 --> 00:00:05,266

Hello everyone, today we are going to learn about the keyboard of the laptop

2

00:00:08,800 --> 00:00:13,366

A keyboard, abbreviated as KB, is the input device of a computer

3

00:00:15,433 --> 00:00:20,766

It's made up of a key cap, a silicone bowl, and this plastic balancing stand

4

00:00:25,566 --> 00:00:28,366

Silicone bowls are elastic silicone buttons

5

00:00:36,500 --> 00:00:39,966

The keyboard is managed by the EC in the mainboard architecture

6

00:00:41,700 --> 00:00:44,233

The EC integrates a keyboard controller

7

00:00:45,666 --> 00:00:49,266

The keyboard communicates with the EC through the keyboard interface

8

00:00:50,900 --> 00:00:54,800

The inside of the keyboard consists of 3 films and a silicone bowl

9

00:01:00,233 --> 00:01:03,266

Circuits are printed on the upper and lower films

10

00:01:08,366 --> 00:01:10,900

Each dot on the top represents a button

11

00:01:14,100 --> 00:01:18,300

Where there are polka dots, there is a circular hole in the middle film

12

00:01:19,100 --> 00:01:23,266

There is no circuit in the middle film, it is the insulation layer

13

00:01:25,433 --> 00:01:26,966

When we press the button,

14

00:01:28,200 --> 00:01:33,466

the silicone bowl makes the upper and lower contact points come together to form a character

15

00:01:37,266 --> 00:01:41,533

These characters are transmitted to the EC through the keyboard's interface

16

00:01:45,333 --> 00:01:47,500

What are the common keyboard failures?

17

00:01:48,666 --> 00:01:52,066

The first type is key adhesion, what dose it mean?

18

00:01:53,266 --> 00:01:56,066

For example, I press the "L" button

19

00:01:56,400 --> 00:01:58,200

and the "P" character pops up

20

00:02:00,766 --> 00:02:03,133

There is also a fault is the character jump

21

00:02:03,433 --> 00:02:08,200

When I don't press any buttons at all, characters appear on the screen themselves

22

00:02:10,366 --> 00:02:14,366

This fault is usually caused by a short circuit of the keyboard itself,

23

00:02:15,466 --> 00:02:20,233

or a leakage of power to the keyboard interface, or the EC itself

24

00:02:23,600 --> 00:02:27,200

The second common fault: the key does not function

25

00:02:27,900 --> 00:02:31,133

This fault is usually caused by a disconnection keyboard,

26

00:02:31,433 --> 00:02:34,333

open interface line, or EC welding

27

00:02:37,500 --> 00:02:43,433

In general, the keyboard is the most likely to damage on a laptop that has water ingress

28

00:02:45,700 --> 00:02:48,666

Ok, this is an introduction of the laptop keyboard
