1

00:00:00,700 --> 00:00:04,700

Hello everyone, today we are going to learn about the touchpad of the laptop

2

00:00:06,866 --> 00:00:10,366

The laptop's touchpad is often abbreviated to TP

3

00:00:13,266 --> 00:00:16,066

It is an input device widely used in laptops

4

00:00:17,333 --> 00:00:20,966

and consists of a touch chip, soft wire and keys

5

00:00:25,466 --> 00:00:28,000

It replaces the mouse on the desktop

6

00:00:30,466 --> 00:00:35,966

In the architecture, the touchpad is managed by the EC through the PS/2 bus

7

00:00:37,533 --> 00:00:43,400

It is also connected to the PCH through the I2C bus to identify the hardware ID

8

00:00:47,800 --> 00:00:50,200

For example, in this architecture,

9

00:00:50,366 --> 00:00:55,400

the PCH identifies the identity information of the touchpad through the I2C bus,

10

00:00:55,733 --> 00:00:57,700

that is, the hardware ID

11

00:00:58,600 --> 00:01:04,333

Its touch signal through touch IC conversion, through PS/2 bus and EC communication

12

00:01:10,266 --> 00:01:12,700

Common faults of the touchpad include:

13

00:01:12,833 --> 00:01:17,700

no response to touch, cursor jumping, or inefficiency

14

00:01:19,766 --> 00:01:23,833

Failure to respond to touch is usually caused by damaged touch IC

15

00:01:23,966 --> 00:01:26,233

or inadequate working conditions

16

00:01:28,633 --> 00:01:31,966

Okay, this is the introduction of the laptop touchpad
