1

00:00:00,500 --> 00:00:04,800

Hello everyone, today we are going to learn about the noun explanation, grounding

2

00:00:08,166 --> 00:00:10,766

Grounding is to supply power to form a loop,

3

00:00:10,833 --> 00:00:15,033

without grounding, no current will flow through the equipment

4

00:00:16,100 --> 00:00:22,000

grounding is also called ground, abbreviated to GND or VSS

5

00:00:22,866 --> 00:00:27,466

Common circuit symbols in circuits are triangles, or three bars

6

00:00:28,466 --> 00:00:31,666

For example, in this Apple's laptop circuit,

7

00:00:32,466 --> 00:00:37,600

its grounding symbol is three horizontal bars, which is GND

8

00:00:38,066 --> 00:00:42,600

The GND for this chip, for example, is this symbol

9

00:00:47,566 --> 00:00:51,866

If the chip is not grounded, it will not work properly

10

00:00:54,366 --> 00:00:57,433

The potential of GND is always 0V

11

00:00:59,333 --> 00:01:05,233

GND has no voltage, It is equivalent to the negative terminal of power supply

12

00:01:05,900 --> 00:01:08,433

Okay, this is the introduction of the grouding
