64. Introduction of signal
In the video, we are going to learn about signals.
Detail
Comments

1

00:00:01,600 --> 00:00:04,566

Hello everyone, today we are going to learn about signals

2

00:00:06,366 --> 00:00:11,500

Signal in theory, the voltage signal only considers the voltage change,

3

00:00:11,600 --> 00:00:16,033

the current of the signal is very small, almost no current

4

00:00:16,833 --> 00:00:18,800

During the operation of the mainboard,

5

00:00:18,900 --> 00:00:22,833

the signal can be pulled up or down as needed at any time

6

00:00:26,133 --> 00:00:30,233

In the circuit diagram, signals are represented by arrows

7

00:00:31,833 --> 00:00:36,600

For example, this kind of arrow, OUT is the output signal,

8

00:00:36,833 --> 00:00:38,633

IN is the input signal,

9

00:00:39,300 --> 00:00:43,300

this kind of arrow with two points is called two-way communication

10

00:00:44,566 --> 00:00:46,066

This is the signal

11

00:00:50,900 --> 00:00:55,100

The direction of the arrow usually indicates the direction of the signal,

12

00:00:55,900 --> 00:00:58,166

but occasionally it can be misdrawn

13

00:01:02,500 --> 00:01:07,033

A signal with an L after it, or this type of signal with an *,

14

00:01:07,466 --> 00:01:10,333

indicates that the signal is active at low level

15

00:01:12,600 --> 00:01:15,866

The high and low levels need to be determined by the circuit

16

00:01:15,933 --> 00:01:18,433

and cannot be limited to a certain value

17

00:01:19,266 --> 00:01:24,600

Normally, 0V is low, and if there is voltage, it is high

18

00:01:26,533 --> 00:01:28,066

In digital circuits,

19

00:01:28,466 --> 00:01:31,733

high levels are represented by 1, or H,

20

00:01:33,000 --> 00:01:36,466

and low levels are represented by 0, or L

21

00:01:38,566 --> 00:01:41,500

So that's a brief description of the signal
