1

00:00:00,266 --> 00:00:03,166

Today we are going to learn what is called PG signal

2

00:00:04,233 --> 00:00:06,200

PG is short for POWER GOOD

3

00:00:10,500 --> 00:00:16,133

The PG signal indicates that the power supply is good and describes that the power supply is normal

4

00:00:16,666 --> 00:00:19,166

It is generally active at high level

5

00:00:25,433 --> 00:00:29,366

For example, the power supply chip U8470,

6

00:00:31,333 --> 00:00:35,466

when it controls generating power, it produces a PG signal

7

00:00:40,333 --> 00:00:43,400

Common abbreviations for PG signal are PG

8

00:00:44,566 --> 00:01:00,100

There are also SYS_PWROK, PCH_PWROK, POK, PWRG, VCCST_PWRGD, PROCPWRGD, etc

9

00:01:00,466 --> 00:01:04,500

These are common PG signal identifiers in circuit diagrams

10

00:01:05,900 --> 00:01:08,500

There are two common PG signal voltages

11

00:01:13,366 --> 00:01:19,533

The PG signal output voltage of a chip similar to this supply is usually 3.3V

12

00:01:20,933 --> 00:01:32,300

The signal voltages of SYS_PWROK, PCH_PWROK and APWROK received by PCH are all 3.3V

13

00:01:33,000 --> 00:01:36,266

After the PCH receives these PG signals,

14

00:01:36,966 --> 00:01:41,233

the PG signal sent to the CPU is usually 1.05V

15

00:01:42,866 --> 00:01:45,200

Okay, so that's the PG signal
