1

00:00:00,266 --> 00:00:04,366

Hello everyone, today we are going to learn about the reset signals

2

00:00:04,800 --> 00:00:11,266

The reset signal is called reset, abbreviated as RST, which means to start over,

3

00:00:11,400 --> 00:00:14,233

that is, to initialize or reset

4

00:00:19,100 --> 00:00:21,766

This reset signal at the beginning of the boot,

5

00:00:22,033 --> 00:00:26,766

it will automatically complete the reset, from low level to high level

6

00:00:27,866 --> 00:00:32,000

During startup, when the CPU receives the switch signal,

7

00:00:32,666 --> 00:00:40,066

the CPU will emit SLP_S3# and SLP_S4# to turn on all power supplies

8

00:00:41,300 --> 00:00:46,233

SLP_S4# is usually used to enable the power supply of S4 state,

9

00:00:47,133 --> 00:00:51,900

such as the main power supply of memory and VPP power supply of memory

10

00:00:52,933 --> 00:01:02,133

SLP_S3# is usually used to enable the power supply of S0 state, VCCST, VCCSTG, etc

11

00:01:04,100 --> 00:01:06,033

After all the power supplies are normal,

12

00:01:06,333 --> 00:01:09,566

these PG signals are finally sent to the CPU

13

00:01:11,466 --> 00:01:21,666

For example, PCH_PWROK, SYS_PWROK, VCCST_PWRGD, CPUPWRGD

14

00:01:22,666 --> 00:01:28,100

They pass through the internal AND gate and delay to produce a platform reset signal,

15

00:01:28,500 --> 00:01:30,666

which will change from low to high

16

00:01:32,100 --> 00:01:37,333

If any power supply is abnormal, such as CPU power supply is abnormal,

17

00:01:38,866 --> 00:01:45,066

the PG signal will not enter the AND gate, and there will be no PCH_PWROK

18

00:01:46,466 --> 00:01:51,166

In the absence of a PG signal, there will be no platform reset signal

19

00:01:52,533 --> 00:01:54,700

If any power supply is abnormal,

20

00:01:55,066 --> 00:01:59,933

this AND gate will not output ALL_SYS_PWRGD,

21

00:02:00,933 --> 00:02:08,266

and there will be no subsequent CPU power, PCH_PWROK, and SYS_PWROK

22

00:02:09,000 --> 00:02:11,500

This is the platform reset signal

23

00:02:12,733 --> 00:02:19,000

When we say no reset in maintenance, we mean that no voltage is measured at the reset test point

24

00:02:20,400 --> 00:02:25,000

The reset test point is usually pin 52 of interface M.2

25

00:02:27,600 --> 00:02:32,700

M.2 Port has two kinds: one is to plug the solid-state disk,

26

00:02:33,633 --> 00:02:36,933

and the other one is to plug the wireless network card

27

00:02:39,566 --> 00:02:44,766

We usually refer to this M.2 interface for wireless card insertion,

28

00:02:46,733 --> 00:02:49,733

whose pin 52 is the platform reset test point

29

00:02:53,533 --> 00:02:58,800

Pin 22 of the Mini PCIe slot is also the platform reset test point

30

00:03:00,500 --> 00:03:04,933

The voltage of platform reset signal is 3.3V

31

00:03:06,566 --> 00:03:10,200

The platform reset is low before the power supply is normal

32

00:03:12,233 --> 00:03:16,933

After the power supply is normal, it will change from low level to high level

33

00:03:17,700 --> 00:03:20,800

This "#" indicates that the low level is valid

34

00:03:21,966 --> 00:03:24,233

After the power supply is normal,

35

00:03:24,933 --> 00:03:29,233

it remains low for a period of time, which is called reseting

36

00:03:31,366 --> 00:03:35,100

When the reset signal changes from a low level to a high level,

37

00:03:35,466 --> 00:03:39,133

it is called a complete reset, or the reset is end

38

00:03:40,266 --> 00:03:42,166

Okay, that's the reset signal
