Hello, everyone, today we're going to learn the chip selection signal

2

00:00:08,000 --> 00:00:10,633

CS can be understood as chip selection

3

00:00:12,600 --> 00:00:15,266

When many chips are connected to the same bus,

4

00:00:17,133 --> 00:00:22,533

a signal is needed to distinguish which chip processes the data and address on the bus

5

00:00:24,900 --> 00:00:28,300

In this case, a chip selection signal is needed

6

00:00:30,200 --> 00:00:35,566

The common names of chip selection signals are CS#, CE#

7

00:00:37,700 --> 00:00:43,266

The chip selection signal usually appears on the SPI bus and is used to read the BIOS

8

00:00:44,766 --> 00:00:49,500

For example, this U6001, which is a FLASH chip

9

00:00:51,400 --> 00:00:54,233

The 1st pin of this FLASH ROM is CE#,

10

00:00:54,733 --> 00:00:56,766

which is the chip selection signal

11

00:00:58,133 --> 00:01:01,566

When the CPU or EC is reading the data in the FLASH ROM,

12

00:01:04,800 --> 00:01:08,266

it can measure the chip selection waveform on this first pin

13

00:01:12,033 --> 00:01:15,333

This waveform is the waveform of the chip selection signal

14

00:01:18,300 --> 00:01:21,733

There are countless times of pulling down as the waveform

15

00:01:22,666 --> 00:01:28,266

The EC or CPU is reading the data in the FLASH ROM when we detect this type of chip waveform

16

00:01:30,500 --> 00:01:32,533

Okay, that's the chip selection signal
