1

00:00:00,600 --> 00:00:03,500

Hello, everyone, let's talk about the enable signal

2

00:00:06,566 --> 00:00:10,333

The enable signal is often called EN, or enable

3

00:00:12,600 --> 00:00:15,900

It is also called ON, OFF, or disable

4

00:00:18,600 --> 00:00:21,700

It is also called SHUTDOWN in some schematics

5

00:00:22,233 --> 00:00:24,366

This EN is short for enable

6

00:00:27,233 --> 00:00:31,200

If there is no # sign, it means that the high level is valid

7

00:00:31,966 --> 00:00:34,566

When it is high level, it is on;

8

00:00:35,800 --> 00:00:38,266

when it is low level, it is off

9

00:00:39,766 --> 00:00:43,600

If it is marked with a #, it means that the low level is valid

10

00:00:45,333 --> 00:00:50,333

When it is low level, it is on; when it is high level, it is off

11

00:00:50,933 --> 00:00:56,266

For example, this SHDN#, SHDN means off

12

00:00:56,600 --> 00:01:03,133

With # is valid for low level, low level means OFF, high level means ON

13

00:01:04,600 --> 00:01:09,100

High and low levels need to be understood in combination with their signal names

14

00:01:09,933 --> 00:01:13,333

The following chip, VR6101

15

00:01:14,666 --> 00:01:16,866

Its 4th pin is an EN signal,

16

00:01:17,966 --> 00:01:21,533

the chip wants to work, first need to get power,

17

00:01:22,666 --> 00:01:25,366

and then get the enable signal of high level

18

00:01:25,633 --> 00:01:30,133

Because the EN does not have a # sign, the high level is valid

19

00:01:30,700 --> 00:01:33,333

When it gets an enable signal of high level,

20

00:01:33,800 --> 00:01:36,533

it outputs power from the OUT pin

21

00:01:38,666 --> 00:01:40,600

Without this EN signal,

22

00:01:42,033 --> 00:01:45,633

the chip will not work and the OUT pin will not output power

23

00:01:46,633 --> 00:01:50,033

That's what the enable signal does, it's like a switch

24

00:01:52,166 --> 00:01:54,100

Okay, that's the enable signal
