1

00:00:00,600 --> 00:00:04,833

Hello everyone, today we are going to learn about the interface of Apple adapter

2

00:00:05,633 --> 00:00:08,800

There are three common interfaces for Apple adapters

3

00:00:11,933 --> 00:00:15,500

The first is the Type-C interface, which is the latest

4

00:00:20,900 --> 00:00:23,600

A little bit older is this T-shaped interface,

5

00:00:24,033 --> 00:00:27,233

and the older one is this toothbrush head interface

6

00:00:28,733 --> 00:00:32,500

Both the T-shaped and the toothbrush head interfaces are magnetic

7

00:00:35,300 --> 00:00:37,766

There's a magnet on the laptop's source,

8

00:00:40,500 --> 00:00:44,366

and when the adapter gets close to the port, it gets caught

9

00:00:47,800 --> 00:00:52,966

The 5 contacts in the adapter are connected to the 5 contacts on the power supply head

10

00:00:59,700 --> 00:01:05,333

The line in the middle of the contact is called intermediate pin, or One-wire bus,

11

00:01:06,933 --> 00:01:10,433

and is used to transmit the power information of the adapter

12

00:01:14,433 --> 00:01:20,133

The two outermost lines are the ground wires, which is the negative terminal of the power supply,

13

00:01:22,000 --> 00:01:24,566

and the two near the middle are the power supplies

14

00:01:26,900 --> 00:01:28,300

There's a lamp up here

15

00:01:29,000 --> 00:01:31,066

And this lamp has three states

16

00:01:32,533 --> 00:01:37,600

When the lamp is off, the communication between the intermediate pins is abnormal,

17

00:01:37,966 --> 00:01:40,366

or the EC conditions are not met

18

00:01:44,233 --> 00:01:46,600

The second state is when it turns green,

19

00:01:47,333 --> 00:01:52,800

indicating that the intermediate light is communicating normally and the battery is fully charged

20

00:01:53,533 --> 00:01:59,000

If it is bright orange, it means that the intermediate pin is communicating normally and charging

21

00:02:02,200 --> 00:02:05,233

The new machine now uses the Type-C adapter

22

00:02:06,200 --> 00:02:09,200

The Type-C adapter does not have the intermediate pin,

23

00:02:09,700 --> 00:02:14,166

but it has a CC bus for transmitting the power information of the adapter,

24

00:02:15,066 --> 00:02:17,666

which we call PD protocol communication

25

00:02:19,300 --> 00:02:22,033

If the CC bus communication is abnormal,

26

00:02:22,800 --> 00:02:26,600

the adapter will not be able to provide proper power to the laptop

27

00:02:28,733 --> 00:02:30,733

Okay, here's the Apple adapter
