1

00:00:01,133 --> 00:00:05,866

Hello everyone, today we are going to learn about the peripheral interfaces of Apple laptop

2

00:00:07,100 --> 00:00:10,400

Typically, older models have more interfaces

3

00:00:14,533 --> 00:00:17,500

New machines now have basically Type-C ports,

4

00:00:18,433 --> 00:00:22,033

no USB ports, lightning ports or DP ports

5

00:00:28,500 --> 00:00:34,166

Older machines like this have RJ45 port, which is connected to a network cable

6

00:00:36,400 --> 00:00:40,233

Next to this is the DP interface and the lightning interface,

7

00:00:42,400 --> 00:00:44,766

a lightning interface, a DP interface

8

00:00:51,333 --> 00:00:57,266

Over here is the USB port, the card reader port, and the headphone port

9

00:00:59,733 --> 00:01:02,666

Slightly newer machines retain the lightning port,

10

00:01:02,800 --> 00:01:05,300

USB port, and headphone port

11

00:01:13,833 --> 00:01:16,933

What is the difference between a lightning port and a DP port?

12

00:01:17,433 --> 00:01:20,533

DP port is mainly used to output video signals,

13

00:01:21,500 --> 00:01:24,033

it can not transmit data and power supply

14

00:01:28,733 --> 00:01:32,766

However, the lightning port integrates the function of the DP port,

15

00:01:33,200 --> 00:01:38,900

and it can transmit data, provide external power, and expand external devices

16

00:01:45,766 --> 00:01:50,100

Therefore, the lightning port is more powerful than the DP port

17

00:01:50,733 --> 00:01:53,533

The latest machines have only the Type-C port,

18

00:01:54,600 --> 00:01:56,733

which can also be called the lightning port

19

00:02:00,166 --> 00:02:05,700

It can be plugged into an adapter for power supply or used to connect to external devices

20

00:02:08,800 --> 00:02:15,366

We can extend USB 3.0, HDMI and other display interfaces through Type-c interface

21

00:02:16,200 --> 00:02:20,900

When we took the laptop apart, there were lots of ports for peripherals

22

00:02:22,433 --> 00:02:24,200

Let's look at them one by one

23

00:02:26,433 --> 00:02:31,600

This interface is connected to the screen wire, it's the screen port,

24

00:02:32,433 --> 00:02:35,233

it's connected to the display through the screen wire

25

00:02:37,433 --> 00:02:43,166

This interface is connected to a WIFI/ Bluetooth, also known as a WIFI/ Bluetooth slot,

26

00:02:45,466 --> 00:02:49,933

which is plugged into a WIFI/ Bluetooth module, or wireless card

27

00:02:59,200 --> 00:03:02,033

This slot is called a solid-state drive slot,

28

00:03:02,666 --> 00:03:05,966

and this is an Apple-specific solid-state drive

29

00:03:11,233 --> 00:03:13,600

This one here is the battery port,

30

00:03:15,366 --> 00:03:20,000

and this one next to the battery port is the backlight cable port for the keyboard

31

00:03:20,866 --> 00:03:22,966

This is the keyboard and touchpad port,

32

00:03:23,766 --> 00:03:27,633

and this is the speaker port, which is the built-in speaker port

33

00:03:30,400 --> 00:03:31,833

The fan port is here

34

00:03:36,800 --> 00:03:39,766

There is a cable connected to the small power board,

35

00:03:40,200 --> 00:03:44,466

which has a USB interface, headphone interface and power interface

36

00:03:46,733 --> 00:03:50,600

The power supply is connected to this interface through another bar

37

00:03:51,366 --> 00:03:53,100

This is the power interface

38

00:03:56,933 --> 00:04:00,600

Okay, so here are some of the peripheral interfaces inside

39

00:04:03,533 --> 00:04:09,233

The shape of these interfaces is not fixed, such as the keyboard touchpad cable interface,

40

00:04:09,733 --> 00:04:12,933

different machines, different widths of the cable

41

00:04:14,600 --> 00:04:19,533

The speaker interfaces of different machines, and the number of wires are also different

42

00:04:20,800 --> 00:04:26,433

There are also this type of cables for small boards, but many models do not have small boards

43

00:04:26,833 --> 00:04:30,533

None of the newer machines will have this WIFI/ Bluetooth slot,

44

00:04:30,900 --> 00:04:32,833

which is soldered to the mainboard

45

00:04:34,833 --> 00:04:41,600

Including this SSD, there will be more machines that weld the SSD chip directly to the mainboard

46

00:04:43,633 --> 00:04:46,700

Okay, so these are the usual peripheral interfaces
