1

00:00:02,166 --> 00:00:09,233

Hello everyone, today will talk about the mainboards A1534, A1706 and A1708

2

00:00:11,200 --> 00:00:15,766

The A1534 is an ultra-low power laptop with a very small mainboard

3

00:00:15,766 --> 00:00:19,066

that takes up only about a quarter of the room inside the machine

4

00:00:22,866 --> 00:00:24,533

There is no fan inside it,

5

00:00:25,700 --> 00:00:28,766

so the sound of the fan can not be heard during operation,

6

00:00:30,733 --> 00:00:32,633

and the heat output is very small

7

00:00:34,100 --> 00:00:36,633

It uses an ultra-low power CPU

8

00:00:39,300 --> 00:00:42,200

Although the mainboard is small, it is well equipped

9

00:00:45,566 --> 00:00:49,533

On the back of the CPU, inside the shield is the memory chip

10

00:00:54,533 --> 00:00:55,766

This is empty

11

00:00:58,166 --> 00:00:59,666

And this is an EC

12

00:01:00,733 --> 00:01:02,833

This is a Wifi/ Bluetooth module

13

00:01:05,133 --> 00:01:08,633

Inside the shield, there's a master chip for the hard drive.

14

00:01:12,366 --> 00:01:14,133

It's a double layered chip

15

00:01:15,466 --> 00:01:18,566

Then this is the solid state drive, SSD

16

00:01:21,133 --> 00:01:25,233

This is also an SSD, one for the front and one for the back

17

00:01:26,100 --> 00:01:29,433

There's a memory chip next to it, for the camera chip

18

00:01:31,866 --> 00:01:34,200

On the back of this Wifi/ Bluetooth module,

19

00:01:34,500 --> 00:01:38,700

there's an antenna switch, and next to it is the antenna socket

20

00:01:43,533 --> 00:01:45,366

This is a power chip over here,

21

00:01:45,900 --> 00:01:48,566

and these CPU power chips and so on

22

00:01:50,066 --> 00:01:51,933

This is the CPU power chip,

23

00:01:52,266 --> 00:01:54,366

and these are all power chips

24

00:01:54,866 --> 00:01:58,233

These power chips control multiple PWM circuits

25

00:02:00,566 --> 00:02:03,233

The components on this mainboard are very dense

26

00:02:05,700 --> 00:02:07,433

This is the screen port

27

00:02:08,066 --> 00:02:10,866

There is a seat here for online BIOS brushing

28

00:02:13,466 --> 00:02:16,800

The BIOS chip is here, in a BGA package

29

00:02:21,666 --> 00:02:26,966

Here are some chips that supply 5 V to the interface, the chips that talk to Type-C

30

00:02:30,166 --> 00:02:32,466

The model uses a Type-C interface

31

00:02:33,066 --> 00:02:34,600

This is the battery port

32

00:02:38,200 --> 00:02:41,333

Let's take a look at the mainboard A1706

33

00:02:42,300 --> 00:02:45,266

It is equipped with hard drives inside these shields,

34

00:02:47,500 --> 00:02:51,666

and the hard drives are controlled here, connected to this seat

35

00:02:54,233 --> 00:02:57,300

There is a buckle to fasten on it and tighten it

36

00:02:59,133 --> 00:03:02,500

If the buckle is loose, the hard disk cannot be read

37

00:03:04,866 --> 00:03:08,400

The latch has to be on so it can communicate with the CPU

38

00:03:08,700 --> 00:03:10,533

It doesn't have a T2 chip

39

00:03:12,766 --> 00:03:14,766

So this must be the processor,

40

00:03:16,466 --> 00:03:19,933

and inside the shield next to the processor is the memory chip

41

00:03:23,200 --> 00:03:28,866

On this side is a Wifi/ Bluetooth module with a socket for a Wifi antenna next to it

42

00:03:34,000 --> 00:03:36,766

Here is a chip that manages the Type-C interface,

43

00:03:39,366 --> 00:03:44,066

also known as the Lightning chip, and here is another Lightning chip

44

00:03:44,766 --> 00:03:47,933

There's a CD3215 on the side,

45

00:03:49,466 --> 00:03:52,300

and there's a CD3215 on the back

46

00:03:56,333 --> 00:03:59,466

Same thing over here, heads, tails

47

00:04:00,400 --> 00:04:04,766

The four CD3215 chips have a white label attached to them

48

00:04:06,833 --> 00:04:11,400

If it turns red, like this one, that means it has water ingress

49

00:04:12,133 --> 00:04:16,000

This is the screen line, the line that connects the screen

50

00:04:16,533 --> 00:04:18,200

This is a battery port

51

00:04:19,966 --> 00:04:22,800

There are only positive and negative outputs

52

00:04:24,566 --> 00:04:28,200

There's a little wire on the battery that connects to the seat

53

00:04:30,433 --> 00:04:34,666

If this small wire is not plugged in, the battery is not discharged,

54

00:04:34,966 --> 00:04:38,033

and the battery voltage can not be measured on the mainboard

55

00:04:38,666 --> 00:04:42,700

Its CPU power supply circuit is DRMOS power supply circuit,

56

00:04:42,866 --> 00:04:45,233

there is no upper and lower tube

57

00:04:48,000 --> 00:04:50,533

This is the main chip that powers the CPU

58

00:04:51,000 --> 00:04:52,433

Where is the EC?

59

00:04:52,900 --> 00:04:54,266

Here is the EC

60

00:04:55,266 --> 00:04:57,633

This is the mainboard A1708

61

00:04:59,466 --> 00:05:03,766

The A1708 mainboard is also powered by an Intel Core processor

62

00:05:11,033 --> 00:05:15,733

It has a feature, this slot is used for the SSD

63

00:05:17,766 --> 00:05:20,266

Next to it is the Type-C interface

64

00:05:21,466 --> 00:05:24,600

There are only two Type-C interfaces on this machine

65

00:05:25,700 --> 00:05:30,800

The chip next to it is the Thunderbolt chip with the CD3215 on the back

66

00:05:36,133 --> 00:05:37,666

This is an EC,

67

00:05:38,500 --> 00:05:40,100

and this is the memory chip

68

00:05:43,400 --> 00:05:45,366

This is also a memory chip

69

00:05:45,966 --> 00:05:48,066

This is a CPU power chip

70

00:05:49,100 --> 00:05:51,100

Its screen line is right here

71

00:05:53,066 --> 00:05:58,433

Here is the Wifi/ Bluetooth module, it is welded to the top, is not pluggable

72

00:05:59,733 --> 00:06:04,366

The label turned red, indicates that the machine had been in the water

73

00:06:05,466 --> 00:06:08,366

Okay, this is the mainboard A1708
