1

00:00:00,466 --> 00:00:06,400

Hello everyone, today we are going to learn about the mainbaords A1990, A2289

2

00:00:08,100 --> 00:00:11,600

A1990 mainboard configuration is relatively high,

3

00:00:13,000 --> 00:00:15,000

using Intel Core processor

4

00:00:20,233 --> 00:00:25,000

There is a PCH here, which is a custom PCH made by Apple

5

00:00:27,400 --> 00:00:31,666

It comes with an independent graphics card, known as a GPU

6

00:00:33,000 --> 00:00:34,666

This is the video memory,

7

00:00:37,133 --> 00:00:39,866

and this right next to the CPU is the memory

8

00:00:41,466 --> 00:00:45,033

There are 16 memory chips, 8 on this side,

9

00:00:45,200 --> 00:00:48,300

8 on the back, 16 memory chips

10

00:00:50,966 --> 00:00:55,033

This is the T2 chip, which is integrated with the EC

11

00:00:58,533 --> 00:01:01,533

There is no BIOS on the mainboard with the T2 chip

12

00:01:03,033 --> 00:01:07,966

The chip next to T2 is called the power chip, also known as PMIC,

13

00:01:08,466 --> 00:01:12,733

which outputs PWM or LDO power supply and so on

14

00:01:15,333 --> 00:01:19,366

It's basically to provide conditions to work on this T2 right here

15

00:01:19,900 --> 00:01:23,366

The power supply inductors surrounding the CPU and graphics card

16

00:01:23,500 --> 00:01:26,033

power supply to the CPU and graphics card

17

00:01:29,266 --> 00:01:30,933

It has four hard drives

18

00:01:31,666 --> 00:01:34,933

This is a hard drive, this is a hard drive,

19

00:01:35,066 --> 00:01:36,833

and two hard drives on the back,

20

00:01:36,966 --> 00:01:38,833

so there are four hard drives

21

00:01:39,533 --> 00:01:41,266

It doesn't have a master chip,

22

00:01:41,600 --> 00:01:45,900

it's integrated inside the T2 chip, so it's very powerful

23

00:01:50,000 --> 00:01:55,866

There are 4 empty pads, which are also used for hard disks, but they are not installed here,

24

00:01:57,700 --> 00:02:03,066

because there are several versions, only the version with higher configuration will be installed

25

00:02:04,133 --> 00:02:07,666

This is a Lightning chip that manages the Type-C interface

26

00:02:09,566 --> 00:02:11,700

This is also a Lightning chip

27

00:02:14,533 --> 00:02:21,633

Over here is the power supply chip for its independent graphics card, which is a PWM controller

28

00:02:23,100 --> 00:02:26,033

Here is a PWM controller powered by the CPU

29

00:02:29,400 --> 00:02:33,766

This kind of graphics card and CPU power consumption is relatively large,

30

00:02:34,466 --> 00:02:39,000

there is no way by the small power chips to provide them with working conditions,

31

00:02:39,833 --> 00:02:43,066

can only use this high-power PWM circuit

32

00:02:46,266 --> 00:02:51,100

Here is a Wifi/ Bluetooth module, and on the back of it is its antenna

33

00:02:52,566 --> 00:02:58,466

On the back of the Type-C interface are two CD3217 and CD3215

34

00:03:02,866 --> 00:03:08,966

We also have a CD3215 on this side, one on the front, one on the back

35

00:03:09,866 --> 00:03:11,833

These chips break a lot

36

00:03:12,400 --> 00:03:14,666

Usually adapter does not boost,

37

00:03:15,833 --> 00:03:21,866

plug in adapter can not open the machine and other faults, mostly with this chip damage

38

00:03:25,933 --> 00:03:28,566

Take a look at the mainboard A2289

39

00:03:33,933 --> 00:03:41,933

In fact, the mainboard configuration and function are similar with the mainboards A2159, A2251

40

00:03:43,800 --> 00:03:45,900

It uses Intel processor

41

00:03:47,500 --> 00:03:50,166

Inside the shield next to the CPU are its memory chips,

42

00:03:50,600 --> 00:03:52,766

two on the front and two on the back

43

00:03:57,133 --> 00:03:59,900

These two white ones are solid-state drives,

44

00:04:01,266 --> 00:04:03,600

and this is also a solid-state drive

45

00:04:04,000 --> 00:04:06,133

There are four solid-state drives

46

00:04:07,066 --> 00:04:11,500

The main control chip of the hard disk is integrated inside the T2 chip

47

00:04:12,733 --> 00:04:16,933

The working conditions of the T2 chip are provided by the power chip next to it

48

00:04:18,333 --> 00:04:24,533

This is a PMIC, power management chip, integrated with multiple power supplies,

49

00:04:24,933 --> 00:04:27,066

which are needed by the CPU

50

00:04:28,300 --> 00:04:30,100

Memory power is usually this

51

00:04:31,000 --> 00:04:34,800

There's a Wifi/ Bluetooth module with an antenna port on the back

52

00:04:39,900 --> 00:04:42,833

There is a lightning chip here in the Type-C interface,

53

00:04:44,466 --> 00:04:48,000

and next to the lightning chip is the CD3215

54

00:04:48,666 --> 00:04:52,666

This is CD3217, we have one on this side,

55

00:04:54,100 --> 00:04:56,700

so we have one on the front, and one on the backc

56

00:04:58,766 --> 00:05:03,666

It has only two Type-C interfaces, which are wired into this position

57

00:05:04,833 --> 00:05:06,833

This is the screen cable port

58

00:05:08,366 --> 00:05:13,533

Ok, this is the introduction of the mainboards A2289 and A2159
