Hello everyone, today we are going to learn about the SMC chip in Apple mainboard

2

00:00:08,300 --> 00:00:11,500

SMC in Apple mainboard is also called EC,

3

00:00:11,700 --> 00:00:15,600

embedded controller, it is a single chip microcomputer

4

00:00:17,366 --> 00:00:22,600

It has an integrated processor, storage space, registers, and so on

5

00:00:26,033 --> 00:00:29,300

It looks like this, it's a small one,

6

00:00:30,466 --> 00:00:33,066

and it has a lot of pads on the bottom

7

00:00:33,400 --> 00:00:35,100

It is a BGA chip

8

00:00:37,533 --> 00:00:42,666

The EC controls the timing of most important signals during system startup

9

00:00:47,500 --> 00:00:48,933

In the shutdown state,

10

00:00:49,033 --> 00:00:52,600

the EC keeps running and waits for the user to power on

11

00:00:56,000 --> 00:01:01,000

Whether you turn it off or on, it is always in the process of working

12

00:01:01,500 --> 00:01:06,166

When it's off, we plug in the adapter, it keeps running

13

00:01:06,933 --> 00:01:10,133

It also manages the charge and discharge of the battery,

14

00:01:11,266 --> 00:01:15,333

monitors the battery level, and waits for the boot at any time

15

00:01:17,633 --> 00:01:21,933

After it is turned on, it controls the speed of the fan,

16

00:01:22,433 --> 00:01:26,200

and monitors the power supply current and voltage of the system

17

00:01:29,033 --> 00:01:33,966

Also adjust the fan, control the status of various indicators

18

00:01:37,333 --> 00:01:42,166

Apple's EC is a little different from the EC of ordinary brand laptops

19

00:01:42,833 --> 00:01:46,500

Apple's EC doesn't have a management keyboard or touchpad,

20

00:01:47,233 --> 00:01:51,866

and the EC is almost built-in, it comes with programs inside

21

00:01:53,666 --> 00:01:57,866

When repairing, we need to find the same mainboard to disassemble

22

00:01:58,566 --> 00:02:02,600

Apple's EC also has a lot of hardware detection capabilities

23

00:02:03,866 --> 00:02:06,000

If the hardware is not compatible,

24

00:02:06,166 --> 00:02:08,966

it will cause slow entry into the system

25

00:02:11,200 --> 00:02:14,200

Special attention should be paid to the machine with water,

26

00:02:14,300 --> 00:02:17,300

such as water in the keyboard and touchpad,

27

00:02:18,000 --> 00:02:20,466

which will lead to slow startup

28

00:02:21,400 --> 00:02:24,666

There are also some voltage and current detection

29

00:02:26,400 --> 00:02:33,466

For example, the SMC_PBUS_VSENSE signal here is the voltage detection of PBUS supply

30

00:02:34,966 --> 00:02:40,466

And CPU current detection, and DCIN's ISENSE and VSENSE,

31

00:02:46,866 --> 00:02:48,900

current and voltage detection

32

00:02:50,433 --> 00:02:55,000

There are some other 5V, 3.3V current detection,

33

00:02:55,166 --> 00:03:00,600

DDR memory current detection, LCD backlight current detection, and so on

34

00:03:03,666 --> 00:03:05,866

So this EC is very powerful

35

00:03:08,000 --> 00:03:12,866

Any one of the supply voltage, current problems, will cause some strange faults

36

00:03:16,300 --> 00:03:21,633

Such as power-off, no display, slow startup and so on

37

00:03:24,900 --> 00:03:27,233

Okay, so that's the EC of Apple
