1

00:00:00,400 --> 00:00:04,400

Hello everyone, today we are going to learn about the working conditions of SMC

2

00:00:07,433 --> 00:00:09,933

SMC is also known as EC

3

00:00:10,733 --> 00:00:15,033

The EC is in the working state whether in the standby state or on state

4

00:00:17,133 --> 00:00:19,966

Let's take a look at how it works in standby mode

5

00:00:25,400 --> 00:00:29,433

First of all, EC has four working conditions

6

00:00:31,200 --> 00:00:37,600

They are standby power supply, standby clock, standby reset and program

7

00:00:38,333 --> 00:00:41,300

Standby supply voltage is 3.3V

8

00:00:42,400 --> 00:00:46,933

Common EC standby power supply names are VBAT and VDDA

9

00:00:47,466 --> 00:00:48,900

In the circuit diagram,

10

00:00:49,066 --> 00:00:52,500

we can find that this is its power supply pin, VBAT

11

00:00:56,300 --> 00:01:02,066

The VDDA is also the power supply pin, and there is a VDD next to the VBAT

12

00:01:02,800 --> 00:01:09,033

This power supply is provided to an external standby power supply PP3V42_G3H

13

00:01:12,200 --> 00:01:14,233

For slightly newer machines,

14

00:01:15,233 --> 00:01:23,033

the standby power name is no longer PP3V42_G3H, but PP3V3_G3H

15

00:01:24,533 --> 00:01:26,300

Standby clock of the EC

16

00:01:30,500 --> 00:01:36,833

Next to the EC there is a crystal oscillator, this one is a 12MHz crystal oscillator,

17

00:01:37,666 --> 00:01:40,100

connected to these two pins of the EC

18

00:01:41,566 --> 00:01:45,533

When the EC meets the power supply, the crystal will vibrate

19

00:01:46,966 --> 00:01:50,933

Without this power supply, the crystal will not work

20

00:01:51,833 --> 00:01:54,666

The EC then delays to get a reset signal,

21

00:01:55,033 --> 00:02:00,633

which is called RST internally and SMC_RESET_L externally

22

00:02:05,800 --> 00:02:09,800

It is a high level reset signal sent by the voltage detection chip

23

00:02:10,933 --> 00:02:17,166

after detecting that the EC standby power supply is normal, and the high level is 3.3V

24

00:02:18,766 --> 00:02:24,100

After the EC meets the requirements of power supply, clock, and reset,

25

00:02:24,600 --> 00:02:28,233

it will read the program and configure the GPIO pin

26

00:02:30,400 --> 00:02:33,866

Because there are many GPIO pins within the EC,

27

00:02:36,266 --> 00:02:40,700

they need to be defined by the program and their functionality assigned by the program

28

00:02:41,766 --> 00:02:47,500

The EC will not work properly until these GPIO pins are configured programmatically

29

00:02:51,333 --> 00:02:57,100

The program resides inside the EC, or it can be called the EC's firmware

30

00:03:00,733 --> 00:03:05,666

EC internal program, we currently have no way to write through the programmer

31

00:03:08,700 --> 00:03:12,633

Therefore, when we encounter EC damage in the maintenance,

32

00:03:13,100 --> 00:03:16,100

we had to find the same mainboard to remove the EC

33

00:03:18,133 --> 00:03:21,066

Well, these are EC's working conditions
