84. T2 chip architecture
In the video, we're going to look at the architecture of Apple's T2 chip.
Detail
Comments

1

00:00:00,333 --> 00:00:04,800

Hello everyone, today we're going to look at the architecture of Apple's T2 chip

2

00:00:06,500 --> 00:00:08,833

The T2 chip is integrated with the EC

3

00:00:09,200 --> 00:00:10,966

It has systems inside it,

4

00:00:15,100 --> 00:00:19,166

and the systems inside it we call the Bridge OS, or firmware

5

00:00:21,333 --> 00:00:24,633

This firmware is writable, it's upgradable

6

00:00:26,533 --> 00:00:28,900

For example, in this architecture,

7

00:00:31,000 --> 00:00:34,266

because of the internal integration of the hard disk controller,

8

00:00:35,166 --> 00:00:40,500

it can directly manage the four hard disk chips on the mainboard through the PCIE bus,

9

00:00:44,366 --> 00:00:47,400

and the four hard disks constitute the disk array

10

00:00:48,933 --> 00:00:53,733

This architecture is drawn with reference to the A1989 model

11

00:00:55,833 --> 00:00:59,066

The architecture of the T2 chip is almost identical

12

00:01:05,366 --> 00:01:10,166

It also manages and communicates with the camera through the MIPI bus

13

00:01:13,966 --> 00:01:19,100

For software to access the camera, it must be authorized by T2

14

00:01:23,533 --> 00:01:27,300

For CPU or PCH to output sound to the speaker,

15

00:01:28,233 --> 00:01:31,733

it also needs to be transmitted out through the T2 chip

16

00:01:35,566 --> 00:01:42,033

To prevent third party software or other rogue software secretly call your camera, or call the microphone

17

00:01:45,233 --> 00:01:49,966

The T2 chip communicates with audio and speakers through the I2S bus

18

00:01:52,033 --> 00:01:58,100

And then there's the UART bus here, which is usually used for near-field communication

19

00:02:03,233 --> 00:02:09,533

Including keyboard, touchpad, touch bar, power IC, charging chip,

20

00:02:10,200 --> 00:02:18,000

battery power identification, temperature detection, screen identification, light sensing,

21

00:02:21,266 --> 00:02:24,666

these communications are controlled by T2 chip

22

00:02:26,200 --> 00:02:29,266

Light sensing refers to ambient light sensing

23

00:02:31,100 --> 00:02:38,200

This includes fingerprints and CD3215 or CD3217 connected to the Type-C interface,

24

00:02:39,266 --> 00:02:41,200

which are controlled by T2

25

00:02:42,700 --> 00:02:46,333

This T2 also has a logic chip and SOC ROM

26

00:02:47,900 --> 00:02:52,200

The capacity of this SOC ROM is not large, not BIOS

27

00:02:54,166 --> 00:02:58,733

As long as the T2 chip is used on the mainboard, there is no BIOS chip

28

00:03:01,133 --> 00:03:08,666

Logic chip, SOC ROM, as well as fingerprint, hard disk, they are bound to the T2 chip

29

00:03:09,866 --> 00:03:14,300

If we want to replace the T2 chip, we have to replace it with the kit,

30

00:03:14,433 --> 00:03:17,066

which means we can't just replace the T2 chip,

31

00:03:22,766 --> 00:03:28,533

we have to replace the fingerprint, the logic chip, and the SOC ROM connected to it

32

00:03:33,433 --> 00:03:36,133

This is the architecture of the T2 chip

33

00:03:38,500 --> 00:03:43,200

The eSPI bus is used to communicate with the PCH or CPU

34

00:03:45,933 --> 00:03:49,133

Some data is communicate with the PCIe bus

35

00:03:51,733 --> 00:03:55,200

Okay, so this is the architecture of Apple's T2 chip
