1

00:00:00,100 --> 00:00:05,433

Hello everyone, today we are going to understand the method of brushing T2 and error instructions

2

00:00:06,266 --> 00:00:11,566

First of all, the T2 brush method is available on Apple's official website

3

00:00:13,266 --> 00:00:16,733

All you have to do is follow the official step-by-step instructions

4

00:00:19,366 --> 00:00:22,900

Next, we will introduce the error in the process of brushing T2锛?

5

00:00:22,933 --> 00:00:24,366

and how to solve it

6

00:00:26,266 --> 00:00:29,933

The first step is to install the latest version of the MAC system

7

00:00:30,166 --> 00:00:32,033

apple configurator 2

8

00:00:35,766 --> 00:00:39,366

The system is not up to date and will report error 10

9

00:00:42,166 --> 00:00:46,133

Second, the computer must enter the DFU mode

10

00:00:48,066 --> 00:00:54,066

Third, in the process of brushing T2, it will first verify the lower layer of T2

11

00:00:56,000 --> 00:00:59,866

At this point, the working conditions of T2 should be normal

12

00:01:00,866 --> 00:01:04,733

Next, verify the upper level RAM of T2

13

00:01:05,433 --> 00:01:09,866

The upper layer will report error 4014 if there is a problem

14

00:01:12,033 --> 00:01:18,600

After the upper layer has no problems, the device on the I2C0 bus of T2 will be verified,

15

00:01:20,500 --> 00:01:23,400

mainly to verify whether the adapter has a boost

16

00:01:24,300 --> 00:01:28,933

Verify the CD3215 or CD3217 chip

17

00:01:29,400 --> 00:01:34,800

If there is a problem, the error 4014 will be reported immediately

18

00:01:39,400 --> 00:01:44,266

After the I2C0 bus of T2 is verified, the hard disk is verified

19

00:01:47,033 --> 00:01:48,733

When verifying the hard drive,

20

00:01:49,233 --> 00:01:51,100

it reads and then writes

21

00:01:51,900 --> 00:01:53,766

The disk is read first

22

00:01:53,900 --> 00:01:59,133

If there is a problem during the read process, error 4014 is displayed,

23

00:01:59,866 --> 00:02:04,733

which generally indicates that the underlying data of the disk is damaged

24

00:02:05,633 --> 00:02:10,833

Write to hard disk, error 9 or 6 will be reported if there is a problem

25

00:02:11,600 --> 00:02:14,966

Error 6 is mostly the hard disk installed backwards,

26

00:02:16,233 --> 00:02:21,000

error 9 is reported, if the screen is on, the hard disk is broken

27

00:02:22,500 --> 00:02:29,500

Error 9 is reported, if the screen is not displayed, there is usually a CPU or PCH problem

28

00:02:29,833 --> 00:02:32,200

Error 9 is the most difficult to fix

29

00:02:33,466 --> 00:02:41,966

After the hard disk is verified, if the T2 logic code chip is verified, error 14 or 27 will be displayed

30

00:02:44,233 --> 00:02:53,266

After verifying the logic chip, verify CPU and PCH, error 75 or 78 will be reported if there is any problem

31

00:02:54,433 --> 00:02:56,566

Next, verify the touchpad

32

00:02:57,133 --> 00:03:03,433

If there is a problem, error -1 will be reported, and the touchpad will not be brushed

33

00:03:04,933 --> 00:03:12,366

Next, we have to verify the fingerprint, and if there is a problem, error 1 will be reported

34

00:03:13,666 --> 00:03:17,366

Ok, here is how to brush T2 and the error description
