1

00:00:00,200 --> 00:00:03,600

Hello everyone, today we are going to learn about BIOS chips

2

00:00:05,833 --> 00:00:08,633

There are three main aspects of the content

3

00:00:10,133 --> 00:00:13,233

The first is a common BIOS chip manufacturers

4

00:00:16,933 --> 00:00:19,400

The second is the common BIOS chip packaging

5

00:00:21,233 --> 00:00:24,333

The third is the capacity identification of BIOS

6

00:00:25,733 --> 00:00:29,166

First, let's take a look at the BIOS chip manufacturers

7

00:00:29,566 --> 00:00:34,133

Common BIOS chip manufacturers include SST, MACRONIX,

8

00:00:34,300 --> 00:00:38,433

WINBOND, cFeon, Microchip, and Micron

9

00:00:41,700 --> 00:00:44,100

These are some common BIOS chip brands

10

00:00:46,266 --> 00:00:49,200

There are usually three types of BIOS chip packaging

11

00:00:49,333 --> 00:00:52,033

The first is the SOP 8 pins package

12

00:00:52,433 --> 00:00:54,400

The second is the QFN package,

13

00:00:54,933 --> 00:00:57,233

which is very common in Apple's machines

14

00:00:59,433 --> 00:01:01,700

The third is a BGA packaged glass chip,

15

00:01:04,033 --> 00:01:07,233

which has this crystal shell and pads on the bottom

16

00:01:14,833 --> 00:01:18,066

Ok, let's look at the BIOS chip capacity identification,

17

00:01:19,233 --> 00:01:22,266

we usually identify its capacity according to its model

18

00:01:24,633 --> 00:01:27,633

First of all, let's take a look at this chip

19

00:01:27,733 --> 00:01:31,766

Its LOGO is MXIC, which is owned by MACRONIX

20

00:01:34,033 --> 00:01:36,166

So this is the manufacturer of the chip

21

00:01:38,000 --> 00:01:40,766

The second row is 25L128,

22

00:01:40,966 --> 00:01:42,800

this is the chip model,

23

00:01:43,233 --> 00:01:45,500

25 refers to 25 series,

24

00:01:45,733 --> 00:01:48,333

128 refers to its capacity

25

00:01:51,133 --> 00:01:53,266

BIOS files are stored in bytes,

26

00:01:56,066 --> 00:01:59,000

128 means 128 megabits

27

00:02:01,366 --> 00:02:06,900

If we look at the suffix, 128 means 128 megabits wide

28

00:02:08,433 --> 00:02:15,866

128 megabits wide, actually can store 16 megabytes, because a byte requires 8 bits

29

00:02:17,466 --> 00:02:21,133

So 16 megabytes is 128 megabits wide

30

00:02:23,900 --> 00:02:28,466

So when we identify the capacity, we divide its mantissa by 8

31

00:02:30,600 --> 00:02:34,966

Divide the suffix of the chip model by 8 to get the actual capacity

32

00:02:38,033 --> 00:02:48,633

For example, if the model is 25L128, divide 128 by 8 to get 16, which indicates 16 megabytes of capacity

33

00:02:49,366 --> 00:02:59,900

For example, this chip 25L4005, 400 divided by 8 is its actual capacity, which is 512 kilobytes

34

00:03:01,933 --> 00:03:07,966

The mantissa is 004/040/400, which means 4 megabits

35

00:03:09,966 --> 00:03:14,100

Like this 25Q64, Q64FV

36

00:03:19,666 --> 00:03:25,533

64 means 64 megabits, so the actual capacity is 8 megabytes

37

00:03:28,733 --> 00:03:31,300

So when we identify the BIOS chip capacity,

38

00:03:32,000 --> 00:03:36,866

we use the chip model suffix divided by 8, is the actual capacity

39

00:03:39,633 --> 00:03:43,100

Ok, this is the identification of the BIOS chip capacity
