Hello everyone, today we are going to learn about Wifi Bluetooth

2

00:00:06,000 --> 00:00:13,100

This lesson is divided into: common Wifi Bluetooth module introduction, Wifi Bluetooth communication bus

3

00:00:13,466 --> 00:00:17,033

Wifi Bluetooth module is also called wireless card module

4

00:00:17,533 --> 00:00:24,833

Since about 2014, Apple laptops have moved away from RJ45 cable ports in favor of wireless cards

5

00:00:30,300 --> 00:00:33,500

This is the wireless card that you can plug in and out

6

00:00:35,633 --> 00:00:37,766

The black one on top is the antenna,

7

00:00:41,333 --> 00:00:43,633

and this is the slot for the network card

8

00:00:44,633 --> 00:00:48,066

The slot is different from the slot in a regular laptop

9

00:00:49,300 --> 00:00:56,800

Therefore, Apple's Wifi Bluetooth module is not universal and interchangeable with ordinary laptops

10

00:00:59,033 --> 00:01:04,000

This wireless card has the characteristics of wide range of wireless signal reception,

11

00:01:04,133 --> 00:01:09,166

strong signal, small heat, stable transmission and so on

12

00:01:11,333 --> 00:01:15,266

It has a range far beyond that of a typical laptop wireless card

13

00:01:19,600 --> 00:01:22,966

The early wireless card was this kind of plug and remove,

14

00:01:23,733 --> 00:01:28,433

the wireless card used in the new model has become a chip welded to the mainboard,

15

00:01:35,066 --> 00:01:42,033

this can also be called Wifi Bluetooth module, which contains both Wifi function and Bluetooth function

16

00:01:43,933 --> 00:01:45,466

Now let's look at its bus

17

00:01:49,066 --> 00:01:50,966

As can be seen from the circuit diagram,

18

00:01:51,433 --> 00:01:54,933

the Wifi module communicates through the PCIE bus

19

00:01:57,033 --> 00:02:01,833

PP3V3_WLAN is the power supply for the Wifi module

20

00:02:04,500 --> 00:02:09,966

Next, there is a wake-up signal for the module, which is the enable signal

21

00:02:11,233 --> 00:02:14,400

The coupling capacitor is connected through PCIE bus

22

00:02:16,300 --> 00:02:21,466

A PCIE bus consists of a pair of sending signals and a pair of receiving signals

23

00:02:22,800 --> 00:02:28,000

There are four PCIE buses and a 100MHz PCIE bus clock

24

00:02:30,466 --> 00:02:35,733

And the reset signal of Wifi module, as well as the network wake up signal,

25

00:02:38,400 --> 00:02:41,400

these belong to the working conditions of wireless card

26

00:02:42,200 --> 00:02:44,566

Bluetooth uses a USB bus

27

00:02:45,566 --> 00:02:49,600

PP3V3_S4 is the Bluetooth power supply

28

00:02:55,833 --> 00:03:00,433

Whether it is welded to the mainboard, or the pluggable Wifi Bluetooth module,

29

00:03:01,233 --> 00:03:05,300

it communicates with the chipset through the PCIE bus and USB bus

30

00:03:07,266 --> 00:03:14,000

Among them, Wifi communicates through PCIE bus, and Bluetooth communicates through USB bus

31

00:03:14,733 --> 00:03:17,066

All right, that's it for this lesson
