1

00:00:00,433 --> 00:00:04,400

Hello everyone, today we are going to learn about Apple PMIC

2

00:00:06,566 --> 00:00:10,566

The PMIC in Apple computers is Apple's own power management chip

3

00:00:17,533 --> 00:00:23,900

The chip is integrated with PWM step-down circuit, LDO circuit and some switching circuit,

4

00:00:29,866 --> 00:00:34,866

such as 3V to 3V, 1V to 1V voltage conversion circuit

5

00:00:35,700 --> 00:00:39,500

It looks like this, and there's a bunch of supply inductors around it,

6

00:00:40,100 --> 00:00:42,333

and these are its output voltages

7

00:00:46,700 --> 00:00:49,666

Each inductor represents a PWM output

8

00:00:50,400 --> 00:00:53,933

But the power consumption of this PWM circuit is relatively small

9

00:00:56,766 --> 00:01:03,700

Its conversion efficiency is not very high and can only power a low-power Apple T2 chip or M1 processor

10

00:01:06,266 --> 00:01:10,266

It doesn't work well with powerful Intel processors or GPUs

11

00:01:15,366 --> 00:01:20,766

For example, this CPU and GPU use traditional PWM power supply

12

00:01:27,966 --> 00:01:34,133

This power supply mode output current is large, the calorific value is also relatively high

13

00:01:35,833 --> 00:01:39,600

Apple's T2 chip, as well as its own M1 processor,

14

00:01:41,333 --> 00:01:44,966

uses its own power management chip, or PMIC

15

00:01:47,333 --> 00:01:50,866

The main power supply and the secondary power supply output each power supply

16

00:01:50,866 --> 00:01:53,300

to meet the working condition of M1

17

00:01:56,800 --> 00:02:03,566

It includes CPU core power supply, memory power supply, and its various modules power supply

18

00:02:09,366 --> 00:02:14,300

The power supply chip generates much less heat than conventional PWM power supply

19

00:02:19,766 --> 00:02:23,000

Okay, so that's the introduction of Apple's PMIC
