Today let's learn about the power supply principle of Apple mainboard

2

00:00:04,733 --> 00:00:08,500

First, let's take a look at the power supply distribution of the mainboard

3

00:00:09,133 --> 00:00:13,600

The power distribution of the mainboard usually adopts the principle of proximity

4

00:00:14,366 --> 00:00:20,100

For example, the circuit that provides power to the CPU is generally close to the CPU

5

00:00:21,400 --> 00:00:27,466

The circuit that provides power to the independent graphics card, usually close to the independent graphics card

6

00:00:28,733 --> 00:00:34,133

For example, this is an independent graphics card, next to its core power supply

7

00:00:34,800 --> 00:00:39,700

This inductor provides a 1.1V voltage for the independent graphics card

8

00:00:40,100 --> 00:00:42,833

and the memory power that powers these memory

9

00:00:45,200 --> 00:00:49,200

For example, the charging inductor is close to the battery interface

10

00:00:51,200 --> 00:00:53,566

There's a solid state drive next to it

11

00:00:55,200 --> 00:00:58,633

The power supply for the hard drive is on the back of the mainboard

12

00:00:59,766 --> 00:01:01,766

Here is the 5V power supply,

13

00:01:02,600 --> 00:01:07,866

here is the 3.3V power supply, and the 5V S4 voltage

14

00:01:09,500 --> 00:01:15,033

Next to the CPU, there is the core power supply of the CPU and the core display power supply,

15

00:01:15,566 --> 00:01:17,033

which are for the CPU

16

00:01:18,000 --> 00:01:20,766

In the mainboard, these large inductors,

17

00:01:21,100 --> 00:01:24,633

each inductor represents a PWM power supply output,

18

00:01:25,466 --> 00:01:28,166

and the ground value of each power supply is different

19

00:01:30,166 --> 00:01:36,033

For example, for the inductors that supply power to the independent graphics card and CPU,

20

00:01:39,466 --> 00:01:44,100

because the power consumption of the CPU and the independent graphics card is relatively large,

21

00:01:45,366 --> 00:01:48,200

the ground value of these inductors is relatively low

22

00:01:49,000 --> 00:01:55,833

The following VCCIO bus power supply, 1V power supply, memory power supply, etc.,

23

00:01:57,366 --> 00:02:00,700

the ground value of these power supplies is relatively high

24

00:02:02,200 --> 00:02:05,300

OK, this is the power supply distribution on the mainboard
