Hello everyone, today we come to understand the Apple mainboard common power supplies

2

00:00:11,100 --> 00:00:13,366

There are five common power supply modes

3

00:00:13,766 --> 00:00:16,200

The first is called switching power supply

4

00:00:16,866 --> 00:00:24,033

This type of power supply usually uses the conduction and cutoff of MOS tube to control the on and off of a voltage

5

00:00:27,166 --> 00:00:31,700

For example, converting the standby voltage to the startup voltage

6

00:00:32,200 --> 00:00:35,766

However, some circuits are converted by power chips

7

00:00:37,366 --> 00:00:40,066

The second is called LDO power supply mode,

8

00:00:40,366 --> 00:00:45,033

also known as low voltage differential linear regulator power supply mode

9

00:00:45,633 --> 00:00:49,000

The power supply mode of LDO is usually step-down type

10

00:00:49,966 --> 00:01:00,100

For example, the 3.3V voltage is reduced to 1.5V, 1.0V, 1.8V to supply power to each other circuit

11

00:01:01,533 --> 00:01:05,866

However, the output current supplied by LDO is very small

12

00:01:06,533 --> 00:01:08,666

The third is PWM power supply

13

00:01:09,233 --> 00:01:11,933

This is the common power supply mode on the mainboard,

14

00:01:12,166 --> 00:01:14,633

but also has the highest failure rate

15

00:01:15,166 --> 00:01:19,733

In laptops, most are PWM circuits in the form of step-down,

16

00:01:25,000 --> 00:01:29,900

It can be a high voltage through the PWM after the step-down, increase the current,

17

00:01:30,066 --> 00:01:35,266

to meet the power of the CPU, graphics card or other circuit power supply needs

18

00:01:41,466 --> 00:01:43,766

The fourth is integrated power supply

19

00:01:44,600 --> 00:01:48,866

The integrated power supply is similar to Apple's main and secondary power chips

20

00:01:51,400 --> 00:01:57,600

It integrates PWM power supply mode, switch power supply mode and LDO power supply mode

21

00:02:01,300 --> 00:02:04,033

This is called integrated power supply mode

22

00:02:05,700 --> 00:02:09,766

The fifth is the four switch step-down, boost power supply circuit

23

00:02:10,666 --> 00:02:15,900

This mode of power supply is usually used to control the generation of a common point voltage,

24

00:02:18,333 --> 00:02:20,500

usually controlled by the charging chip

25

00:02:23,066 --> 00:02:26,733

Ok, these are the five common power supply modes in the mainboard
