Hello everyone, today we are going to understand the LDO power supply mode output by the voltage regulator

2

00:00:09,966 --> 00:00:14,600

First, LDO stands for low voltage differential linear regulator,

3

00:00:15,866 --> 00:00:20,000

which can achieve very small voltage difference between output and input

4

00:00:20,600 --> 00:00:24,700

This supply circuit is characterized by its direct output from the chip

5

00:00:25,433 --> 00:00:32,200

Direct output from this OUT pin, no inductor at the output end, but a filter capacitor

6

00:00:33,266 --> 00:00:37,666

The disadvantage is low output current and high loss, such as here

7

00:00:38,366 --> 00:00:40,166

The chip works like this

8

00:00:43,500 --> 00:00:46,900

The BIAS pin is the operation voltage of the chip

9

00:00:47,700 --> 00:00:55,533

This IN is the voltage input, provided by PP1V8_S3, 1.8V power supply input

10

00:00:57,266 --> 00:01:02,133

And then when it gets the third pin EN, it's going to output OUT

11

00:01:08,166 --> 00:01:16,066

The voltage output from the OUT pin is 1.5V and the maximum current is 0.02A

12

00:01:18,866 --> 00:01:22,400

The current is very small, 20 mA

13

00:01:25,466 --> 00:01:30,700

And it is the step-down type, step-down 1.8V to 1.5V

14

00:01:31,200 --> 00:01:36,000

It has a step-down and low current, and that's an LDO circuit

15

00:01:36,466 --> 00:01:39,900

Take a look at this chip, U7840,

16

00:01:40,500 --> 00:01:42,900

which is also an LDO power chip

17

00:01:44,800 --> 00:01:47,133

Pins 3, 4, and 6

18

00:01:49,200 --> 00:01:56,766

Its power supply, input voltage and turn on signal are provided by PP3V3_SUS

19

00:01:58,066 --> 00:02:02,833

This chip can provide power, and has enable signal and input,

20

00:02:03,366 --> 00:02:06,866

it converts the input voltage into an OUT output

21

00:02:07,800 --> 00:02:15,500

Here, the output is PP1V05_SUS, indicating 1.05V power output

22

00:02:17,233 --> 00:02:22,800

It converts 3.3V to 1.05V, which has a vlotage drop

23

00:02:23,566 --> 00:02:29,533

Its maximum output current is 0.35A, which is very small

24

00:02:30,833 --> 00:02:35,000

But the current in PP3V3_SUS is very high

25

00:02:37,033 --> 00:02:41,700

If every power supply uses LDO, the loss is too great

26

00:02:45,333 --> 00:02:50,833

Therefore, LDO power supply mode is usually used in some low-power circuits

27

00:02:52,400 --> 00:02:57,633

For example, it provides standby power to the EC and RTC circuits

28

00:02:59,166 --> 00:03:02,900

In this very low power circuit, LDO is used

29

00:03:08,366 --> 00:03:13,433

Well, this is the LDO power supply mode of the voltage regulator output
