Hello everyone, today let's learn the LDO power supply mode

2

00:00:04,233 --> 00:00:06,666

of charging chip and standby chip output

3

00:00:10,433 --> 00:00:13,566

In this lesson, we will introduce two chips,

4

00:00:14,300 --> 00:00:17,500

one is the charging chip, the other is the standby chip

5

00:00:17,733 --> 00:00:20,666

Let's first take a look at the LDO of charging chip

6

00:00:22,300 --> 00:00:25,266

For example, U8800A,

7

00:00:25,833 --> 00:00:29,133

its model is BQ24725,

8

00:00:30,266 --> 00:00:33,533

and its REGN pin is the LDO output pin

9

00:00:37,433 --> 00:00:40,633

According to the information provided in the chip data book,

10

00:00:41,400 --> 00:00:45,100

pin 16 REGN is a linear regulator output

11

00:00:45,700 --> 00:00:51,166

REGN can output 6V linear, its power supply is from the VCC

12

00:00:51,866 --> 00:00:56,200

The VCC voltage must be greater than 6.5V,

13

00:00:56,566 --> 00:01:00,966

and the ACDET pin must have a voltage greater than 0.6V

14

00:01:04,566 --> 00:01:12,666

Then REGN can output 6 volts of linear, minimum 5.5V, maximum 6.5V

15

00:01:15,633 --> 00:01:23,500

At the linear output, a 1uF ceramic capacitor needs to be connected, grounded from the REGN pin

16

00:01:24,666 --> 00:01:29,533

In the actual circuit, this is the capacitor C8812

17

00:01:34,066 --> 00:01:41,166

Each linear output terminal is connected with a filter capacitor to ensure that its output voltage is more stable

18

00:01:43,166 --> 00:01:45,766

The basic process of how this chip works

19

00:01:46,666 --> 00:01:49,233

First it has to get VCC power

20

00:01:50,833 --> 00:01:54,200

Second, the ACDET pin needs to get a high level,

21

00:01:54,866 --> 00:01:57,233

and then the REGN will be generated

22

00:01:58,000 --> 00:02:00,900

This is a linear voltage generation process

23

00:02:03,400 --> 00:02:07,800

Next, let's take a look at the LDO output from the standby chip

24

00:02:09,833 --> 00:02:15,266

For example, this RT6575D, RT6575C

25

00:02:15,766 --> 00:02:19,100

It is a very common standby power supply chip in laptops

26

00:02:22,633 --> 00:02:27,766

The LDO3 pin of this chip is the 3.3V LDO output pin,

27

00:02:31,100 --> 00:02:35,266

and the LDO5 pin is the 5V LDO output pin

28

00:02:40,800 --> 00:02:43,033

The chip's workflow is simple

29

00:02:43,600 --> 00:02:50,700

It produces two linear outputs, LDO3 and LDO5, as long as it is powered

30

00:02:52,233 --> 00:02:54,800

The power supply is this VIN

31

00:02:57,500 --> 00:03:04,166

In addition to standby power supply chips and charging chips that can generate LDO linear output by themselves,

32

00:03:05,000 --> 00:03:10,233

there are many chips in the circuit that can generate LDO linear output by themselves,

33

00:03:11,433 --> 00:03:14,633

such as memory power supply chips and so on

34

00:03:18,533 --> 00:03:21,133

All right, that's it for this lesson
