Hello everyone, today we are going to learn about the waveforms in PWM circuit

2

00:00:07,500 --> 00:00:10,966

Here, we focus on the upper and lower tube G-pole waveforms

3

00:00:10,966 --> 00:00:14,133

and the waveforms at the front and back of the inductor

4

00:00:16,300 --> 00:00:20,633

First of all, when the common point voltage is 19V,

5

00:00:22,966 --> 00:00:27,133

the peak value of the G pole of the upper tube is about 24V

6

00:00:29,633 --> 00:00:35,566

The blue wave is 10V per grid, so channel 2 is 10V per grid

7

00:00:39,100 --> 00:00:42,133

It takes up about two and a half grids here,

8

00:00:42,266 --> 00:00:43,933

so it's about 24 volts

9

00:00:46,166 --> 00:00:53,400

The peak at the G pole of the lower tube is 5V per grid, which is 5V per grid for channel 1

10

00:00:55,233 --> 00:01:01,500

It occupies exactly one grid, so the peak G of the lower tube is 5V

11

00:01:03,666 --> 00:01:07,766

Their PWM frequency is 330KHz

12

00:01:09,700 --> 00:01:13,900

This is the pulse waveform at the G pole of the upper and lower tubes

13

00:01:14,733 --> 00:01:19,433

Upper tube G is very high level, control the upper tube conduction

14

00:01:20,466 --> 00:01:25,666

Upper tube G is very low level, control the upper tube cutoff

15

00:01:27,333 --> 00:01:33,033

When the lower tube G is extremely high, control the conduction of the lower tube

16

00:01:33,600 --> 00:01:38,666

When the lower tube G is extremely low, control the lower tube cutoff

17

00:01:39,833 --> 00:01:45,166

From here, we can see that the conduction time of the upper tube is very short,

18

00:01:46,233 --> 00:01:52,966

the high level time of the lower tube is very long, and the conduction time of the lower tube is long

19

00:01:54,600 --> 00:02:02,400

The PWM chip will adjust the output voltage by controlling the duty cycle of the upper and lower tube pulses

20

00:02:09,333 --> 00:02:14,133

The output current can be adjusted by controlling the pulse frequency

21

00:02:19,600 --> 00:02:23,233

Now let's look at the waveforms at the front of the inductor

22

00:02:25,466 --> 00:02:31,600

The peak value of the front end of the inductor is equal to the peak value of the common point voltage

23

00:02:32,833 --> 00:02:35,233

This is coming through the upper tube

24

00:02:36,466 --> 00:02:39,066

Channel 1 is the inductor back end,

25

00:02:40,466 --> 00:02:42,233

it is a direct current

26

00:02:45,166 --> 00:02:49,066

Channel 2 is the front end of the inductor, which is a pulse

27

00:02:51,066 --> 00:02:55,866

Okay, this is the introduction of the common PWM circuit waveforms
