Hello everyone, today we are going to learn about the self-lift voltage in PWM circuit

2

00:00:06,200 --> 00:00:10,833

Here we first review the waveform sof the upper and lower tube G poles,

3

00:00:11,633 --> 00:00:14,433

and then introduce the self-lift voltage

4

00:00:16,633 --> 00:00:18,866

We have learned that in the last lesson,

5

00:00:19,333 --> 00:00:22,100

When the common point voltage is 19V,

6

00:00:23,100 --> 00:00:27,133

the peak value of G pole of the upper tube is about 24V,

7

00:00:28,366 --> 00:00:32,466

and the peak value of G pole of the lower tube is about 5V

8

00:00:34,200 --> 00:00:37,600

So where does the upper tube 24V come from?

9

00:00:40,266 --> 00:00:43,966

That's the self-lift voltage that we're going to talk about

10

00:00:46,566 --> 00:00:48,333

Like this PWM chip

11

00:00:50,533 --> 00:00:55,633

When the VIN pin of the chip and the D pole of the upper tube get a common point voltage,

12

00:01:00,600 --> 00:01:04,566

the integrated LDO power supply inside the chip starts to work

13

00:01:12,700 --> 00:01:16,333

First, a 5V LDO output is generate

14

00:01:16,800 --> 00:01:21,366

It will be used by external circuits as well as internal chips

15

00:01:22,166 --> 00:01:27,133

This 5V linear provides power to this pin through an internal diode

16

00:01:28,533 --> 00:01:34,766

At the same time, this pin will be connected to the external self-lift voltage capacitor

17

00:01:35,333 --> 00:01:41,266

This capacitor is actually a normal capacitor, it's not grounded at both ends

18

00:01:42,066 --> 00:01:46,266

One end of it is connected to the chip's self-lift voltage pin,

19

00:01:46,433 --> 00:01:50,133

and the other end is connected to the front end of the inductor

20

00:01:55,466 --> 00:01:59,166

Before T1 time period, the upper tube is not on,

21

00:01:59,366 --> 00:02:02,766

and there is no electricity at the front end of the inductor

22

00:02:05,900 --> 00:02:09,233

At this point, the capacitor is being charged

23

00:02:09,533 --> 00:02:13,333

5V at one end and 0V at the other,

24

00:02:14,466 --> 00:02:17,266

and it's charged with a 5V voltage

25

00:02:18,233 --> 00:02:23,333

When entering the T1 period, the upper tube starts to conduct

26

00:02:26,266 --> 00:02:31,466

At this time, the driving voltage of the upper tube G pole comes from the BOOT pin

27

00:02:32,500 --> 00:02:40,400

The BOOT pin has 5V, which can provide drive level to the G pole of the upper tube, up to 5V

28

00:02:41,700 --> 00:02:49,566

But in the case of an S pole without power, 5V is enough to get it fully on in an instant

29

00:02:50,766 --> 00:02:57,266

The high level that it leads through instantaneously will be superimposed to the other end through the capacitor,

30

00:02:58,133 --> 00:03:01,766

and the original 5V linear voltage will be superimposed

31

00:03:06,300 --> 00:03:09,400

Then it gets a boost of 13.6V

32

00:03:09,833 --> 00:03:14,966

Therefore, in the second cycle, it can output a higher drive level

33

00:03:19,700 --> 00:03:26,333

Common self-lift voltage pins are BOOT, BOOST, BST, VBST

34

00:03:32,566 --> 00:03:34,600

The pin is called a starter pin,

35

00:03:35,133 --> 00:03:40,000

which can also be called a self-lift voltage pin, or a base voltage pin

36

00:03:42,033 --> 00:03:47,633

The purpose of the self-lift voltage is to drive the upper tube to complete conduction

37

00:03:49,200 --> 00:03:57,200

If the self-lift voltage is insufficient, the upper tube can not be completely conduction, easy to burn the tube

38

00:03:57,933 --> 00:04:00,600

Okay, so that's what the bootstrap is for

39

00:04:02,600 --> 00:04:05,633

This is the introduction to self-lift voltage
